7 - 9
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R458 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 24.1/26.9
R459 7030005530 S.RES ERJ2GEJ 100 X (10) B 20.2/27.3
R460 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 22.2/21.9
R461 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 21.3/22
R462 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 19.3/27.8
R500 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 31.2/36.5
R501 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 28.8/35.4
R502 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 28.9/32.5
R503 7030005060 S.RES ERJ2GEJ 333 X (33 k
)
T 32.9/30.2
R504 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 32.9/31.1
R506 7030004990 S.RES ERJ2GEJ 221 X (220) T 28.2/31.3
R507 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
T 28/25.2
R508 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
T 30.5/26.4
R509 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 28.9/28.2
R510 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 29.6/26.4
R511 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 29.6/20.4
R512 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
T 31.8/19.1
R513 7030005530 S.RES ERJ2GEJ 100 X (10) T 29/16.5
R514 7030004990 S.RES ERJ2GEJ 221 X (220) T 28.6/18.6
R515 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 30.9/16.3
R516 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 15.7/11.7
R517 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
T 28.8/36.3
R518 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 31.4/38.8
R602 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 25.8/34.1
R603 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 25.8/33.2
R604 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 30.8/33.2
R605 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 32/33.6
R607 7030004990 S.RES ERJ2GEJ 221 X (220) B 25.5/32
R609 7030005530 S.RES ERJ2GEJ 100 X (10) B 26.1/36.2
R610 7030004980 S.RES ERJ2GEJ 101 X (100) B 27.8/27.3
R611 7030004980 S.RES ERJ2GEJ 101 X (100) B 30.2/26.3
R612 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 26/24.7
R613 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 24.9/23.5
R614 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 22.5/15.8
R615 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 24.9/17.1
R616 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 23.7/14.2
R617 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 23.7/15.4
R618 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 24.9/16.2
R619 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 19.7/16.7
R620 7030004990 S.RES ERJ2GEJ 221 X (220) B 20.5/19.6
R621 7030005530 S.RES ERJ2GEJ 100 X (10) B 17.9/17.1
R622 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 20.9/11.6
R623 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 19.7/11
R624 7030009270 S.RES ERJ2GEJ 821 X (820) B 16.3/16.1
R650 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 31.2/22.3
R651 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 31.5/21.1
R652 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 28.8/19.1
R653 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 30.6/19.7
R654 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 32.7/16.9
R655 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 32.7/17.8
R656 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 33.2/19.7
R657 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 32.4/14.8
R658 7030004990 S.RES ERJ2GEJ 221 X (220) B 27.9/15
R659 7030005530 S.RES ERJ2GEJ 100 X (10) B 27.9/14.1
R660 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 33.6/11.5
R661 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 31.7/10.3
R662 7030009270 S.RES ERJ2GEJ 821 X (820) B 27.9/13.2
R700 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 2.4/38.2
R701 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 2.6/35
R702 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 3.2/33.5
R703 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
B 5.6/26.5
R704 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
B 5.6/27.4
R705 7030004970 S.RES ERJ2GEJ 470 X (47) B 7.9/22.5
R706 7030010040 S.RES ERJ2GEJ-JPW B 5.1/23.7
R707 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 2/29.9
R708 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 6.6/17
R709 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 5.7/17
R710 7030007250 S.RES ERJ2GEJ 220 X (22) B 10.3/15.3
R711 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 9.1/15.9
R712 7030007280 S.RES ERJ2GEJ 331 X (330) B 9.1/12.5
R713 7030004990 S.RES ERJ2GEJ 221 X (220) B 8.6/14.6
R714 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 11.9/12.1
R715 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 12.7/16.3
R800 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 24.1/20.9
R801 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 18.3/25.8
R802 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 21.7/25.1
R803 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 22.6/25.1
R804 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 23.9/22.7
R805 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 24.1/21.8
R806 7030011170 S.RES RR0510P-471-D (470) T 9.5/18.5
R807 7030009190 S.RES RR0510P-332-D (3.3 k
)
T 11.2/22.9
R808 7030005990 S.RES RR0510P-122-D (1.2 k
)
T 9.5/19.4
R811 7030010040 S.RES ERJ2GEJ-JPW T 14/21.9
R815 7030010040 S.RES ERJ2GEJ-JPW T 10.6/17.1
R818 7030004980 S.RES ERJ2GEJ 101 X (100) T 24.8/15.7
R819 7030009530 S.RES ERJ2GEJ 270 X (27) T 19.2/16.2
R820 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 19.6/18.4
R821 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
T 22.1/15.7
R822 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
T 21.2/15.7
R823 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 46.1/17.1
R824 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 41.3/17.8
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R830 7030010090 S.RES ERJ2GEJ 180 X (18) T 18.8/24.6
R831 7030010090 S.RES ERJ2GEJ 180 X (18) T 17.1/24
R832 7030010090 S.RES ERJ2GEJ 180 X (18) T 23.3/19.7
R850 7030004970 S.RES ERJ2GEJ 470 X (47) T 13.7/11.1
R851 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
T 12.8/10.8
R852 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
)
T 14.5/12.3
R853 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 16.1/12.3
R854 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
T 15.8/7
R855 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 15.8/5.3
R900 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 12.7/10.4
R901 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 27.9/11.7
R962 7030004970 S.RES ERJ2GEJ 470 X (47) T 22.4/27.2
R970 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 7/31.7
R971 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 7.4/32.9
R972 7030007270 S.RES ERJ2GEJ 151 X (150) T 11.5/30.1
R973 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 24.5/33.2
R974 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 24/32
R975 7030007270 S.RES ERJ2GEJ 151 X (150) T 20.2/29.6
R976 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 23.8/28.6
R977 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 24.7/28.6
R978 7030007270 S.RES ERJ2GEJ 151 X (150) T 20.8/27.5
R980 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 7.3/24.7
R981 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
T 7.3/26.3
R982 7030007270 S.RES ERJ2GEJ 151 X (150) T 11.5/28.5
R983 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 7.9/31.7
R1000 7030010040 S.RES ERJ2GEJ-JPW B 36.8/10.7
R1001 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 37.5/12.3
C1 4030017560 S.CER ECJ0EC1H2R5B T 10.1/43.8
C2 4030017380 S.CER ECJ0EC1H050B T 11.3/44.1
C3 4030017350 S.CER ECJ0EC1H020B T 14.5/40.7
C4 4030017380 S.CER ECJ0EC1H050B T 12.2/44.1
C5 4030017350 S.CER ECJ0EC1H020B T 16.1/40.7
C6 4030017560 S.CER ECJ0EC1H2R5B T 16.3/43.8
C7 4030017400 S.CER ECJ0EC1H220J T 21.8/41.5
C8 4030017400 S.CER ECJ0EC1H220J T 23.4/41.6
C9 4030017400 S.CER ECJ0EC1H220J T 23/40.6
C10 4030017550 S.CER ECJ0EC1H1R5B T 20.6/42.3
C11 4030017660 S.CER ECJ0EC1H330J T 21.8/42.4
C12 4030017580 S.CER ECJ0EC1H060C T 20.6/43.9
C13 4030017400 S.CER ECJ0EC1H220J T 21.8/43.3
C14 4030017550 S.CER ECJ0EC1H1R5B T 21.8/44.2
C16 4030017550 S.CER ECJ0EC1H1R5B B 4.9/40.1
C17 4030017550 S.CER ECJ0EC1H1R5B B 4.2/38.2
C18 4030017380 S.CER ECJ0EC1H050B B 3.3/38.2
C20 4030017440 S.CER ECJ0EC1H221J B 33.4/43.2
C22 4030017460 S.CER ECJ0EB1E102K B 30.7/47.5
C23 4030016790 S.CER ECJ0EB1C103K B 27/45.3
C25 4030017440 S.CER ECJ0EC1H221J B 32.9/45.7
C26 4030017460 S.CER ECJ0EB1E102K T 29.7/43
C27 4030017460 S.CER ECJ0EB1E102K T 34.6/45.3
C28 4030017380 S.CER ECJ0EC1H050B B 25/42.4
C29 4030017620 S.CER ECJ0EC1H100C B 24.9/39.7
C30 4030017460 S.CER ECJ0EB1E102K B 29.6/39.7
C31 4030017460 S.CER ECJ0EB1E102K B 34.3/40.3
C32 4030017460 S.CER ECJ0EB1E102K B 30.8/39.8
C34 4030017460 S.CER ECJ0EB1E102K T 27.7/47.9
C35 4030017460 S.CER ECJ0EB1E102K T 28.5/45.7
C36 4030017460 S.CER ECJ0EB1E102K T 35/47.7
C37 4030017390 S.CER ECJ0EC1H180J B 26.3/46.2
C38 4030017390 S.CER ECJ0EC1H180J B 23.7/45
C39 4030018860 S.CER ECJ0EB0J105K B 23.7/47.1
C40 4030017460 S.CER ECJ0EB1E102K B 20.2/48.1
C41 4030018860 S.CER ECJ0EB0J105K B 22.1/45.9
C43 4030017330 S.CER ECJ0EF1C104Z T 24.7/45.6
C44 4030017460 S.CER ECJ0EB1E102K T 32.6/40.9
C45 4030017460 S.CER ECJ0EB1E102K T 24.7/47.2
C46 4030016790 S.CER ECJ0EB1C103K B 27.6/41.3
C47 4030017340 S.CER ECJ0EC1H010B B 5.3/39.2
C48 4030017460 S.CER ECJ0EB1E102K B 23.8/41.1
C49 4030017400 S.CER ECJ0EC1H220J B 19/47.8
C100 4030017670 S.CER ECJ0EC1H390J T 32.1/39.7
C101 4030017610 S.CER ECJ0EC1H090C [USA], [USA-1] T 33.8/35.2
4030017620 S.CER ECJ0EC1H100C
Except [USA], [USA-1] T 33.8/35.2
C102 4030006990 S.CER C1608 CH 1H 080D-T
[USA], [USA-1] T 35.9/34
4030007010 S.CER C1608 CH 1H 100D-T
Except [USA], [USA-1] T 35.9/34
C103 4030007030 S.CER C1608 CH 1H 150J-T T 35.9/35.2
C104 4030007070 S.CER C1608 CH 1H 330J-T T 37.4/32.8
C106 4030017350 S.CER ECJ0EC1H020B T 28.5/44.1
C107 4030011540 S.CER C1608 CH 1H 750J-T T 33.7/41
C108 4030017460 S.CER ECJ0EB1E102K T 38/23.2
C109 4550007650 S.TAN F931V105MAABMA T 33.7/23.1
C110 4030017460 S.CER ECJ0EB1E102K
C112 4030017420 S.CER ECJ0EC1H470J
Except [USA], [USA-1] T 43.9/24.9
4030017500 S.CER ECJ0EC1H560J [USA], [USA-1] T 43.9/24.9
C113 4030017460 S.CER ECJ0EB1E102K T 45.1/30.4
To Next Page
