7 - 12
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[VCO UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
Q1 1530003560 S.TR 2SC5195-T1 T 10.4/16.5
Q2 1590003280 S.TR UNR9211J-(TX) T 4.6/15.1
Q51 1530003560 S.TR 2SC5195-T1 T 14/9.6
Q52 1590003280 S.TR UNR9211J-(TX) T 18.1/17.4
Q101 1530003260 S.TR 2SC5006-T1 T 9/2.5
Q102 1590003280 S.TR UNR9211J-(TX) T 19/1.8
Q200 1530003260 S.TR 2SC5006-T1 T 8.8/10.9
Q201 1530003260 S.TR 2SC5006-T1 T 3.8/3.5
Q202 1530003260 S.TR 2SC5006-T1 T 5.6/11.4
D1 1750001270 S.VCP 1SV325 (TPH3) T 3.2/18
D2 1790001621 S.DIO 1SV308 (TPL3) T 7.1/16.3
D3 1750001270 S.VCP 1SV325 (TPH3) T 12.2/15.5
D4 1750000940 S.DIO ISS400 TE61 T 12.8/18.9
D5 1750001270 S.VCP 1SV325 (TPH3) T 4.4/17.3
D6 1750001270 S.VCP 1SV325 (TPH3) T 12.2/14.3
D51 1750000771 S.VCP HVC376BTRF-E T 16.5/14.2
D52 1790001260 S.DIO MA2S077-(TX) T 14.6/17.7
D53 1750000940 S.DIO ISS400 TE61 T 12.4/7.4
D54 1750001270 S.VCP 1SV325 (TPH3) T 15.6/12.4
D55 1720000650 S.VCP 1SV286 (TPH3) T 17.4/10.6
D100 1720000650 S.VCP 1SV286 (TPH3) T 17.4/1.6
D101 1750000721 S.VCP HVC375BTRF-E T 12.2/2.2
D102 1790001260 S.DIO MA2S077-(TX) T 16.8/5.4
D103 1750000940 S.DIO ISS400 TE61 T 7.4/1.6
D104 1750000721 S.VCP HVC375BTRF-E T 13.9/3.1
L2 6200011650 S.COL LQW18AN68NG00D T 6.8/18.3
L3 6200011660 S.COL LQW18ANR15G00D T 5/19.1
L52 6200010850 S.COL LQW18AN22NG00D T 14.7/13.9
L53 6200012050 S.COL LQW18AN24NG00D T 14.7/15.1
L101 6200011031 S.COL ELJRF R10JFB T 7.6/3.5
L102 6200010120 S.COL LQW18AN5N6C00D T 12.3/4.7
L103 6200012060 S.COL LQW18AN9N1D00D T 14.1/5.4
L200 6200011021 S.COL ELJRF 82NJFB T 2.3/1.5
L201 6200011021 S.COL ELJRF 82NJFB T 4/11.9
L202 6200007951 S.COL ELJRF 8N2JFB (8.2) T 3.6/10.1
L203 6200007931 S.COL ELJRF 12NJFB T 4.1/1.5
L204 6200007961 S.COL ELJRF 6N8JFB (6.8) T 6.3/5
R1 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 6.2/15
R2 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 8/15
R3 7030004970 S.RES ERJ2GEJ 470 X (47) T 10.7/18.8
R4 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 10.7/17.9
R5 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 9.1/18.8
R6 7030005710 S.RES ERJ2GEJ 121 X (120) T 10/13.8
R7 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 11.6/12.4
R8 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 2.8/16.4
R9 7030010040 S.RES ERJ2GEJ-JPW T 11.6/13.3
R10 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 7.1/15
R50 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 17.5/13.9
R51 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 16.5/17.2
R52 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 15.6/16.4
R53 7030004970 S.RES ERJ2GEJ 470 X (47) T 12.8/8.4
R54 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
)
T 15.5/9.5
R55 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 16.4/9.5
R56 7030007270 S.RES ERJ2GEJ 151 X (150) T 12.3/10.2
R58 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
T 18.9/11.8
R59 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
T 19.8/10.2
R60 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 13.8/16.4
R61 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
)
T 19.8/13.4
R62 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 17.7/12.7
R100 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 14.3/1.5
R101 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 17.9/6.5
R102 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 15.6/6.5
R104 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
T 9.2/1
R105 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 9/4.7
R106 7030004990 S.RES ERJ2GEJ 221 X (220) T 10.2/5.6
R107 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 18.2/7.4
R108 7030007320 S.RES ERJ2GEJ 225 X (2.2 M
)
T 16.6/7.4
R109 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
T 16.6/8.3
R110 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
T 18.9/10.2
R111 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 15.2/3.3
R112 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 16.6/4.1
R113 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 20.2/16.2
R114 7030010040 S.RES ERJ2GEJ-JPW T 19.4/3.4
R115 7030010040 S.RES ERJ2GEJ-JPW T 17.8/3.4
R116 7030004980 S.RES ERJ2GEJ 101 X (100)
[USA-1] only T 10/8.2
R200 7030009160 S.RES ERJ2GEJ 181 X (180) T 7.5/13.2
R201 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
T 9.5/9.4
R202 7030005300 S.RES ERJ2GEJ 150 X (15) T 8.9/7
R203 7030005570 S.RES ERJ2GEJ 820 X (82) T 7.7/8.2
R204 7030005570 S.RES ERJ2GEJ 820 X (82) T 7.3/7
R205 7030004970 S.RES ERJ2GEJ 470 X (47) T 2.1/2.7
R206 7030005060 S.RES ERJ2GEJ 333 X (33 k
)
T 5.3/3.9
R207 7030004970 S.RES ERJ2GEJ 470 X (47) T 5.9/8.1
R208 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
T 5.9/9
[VCO UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C1 4030017460 S.CER ECJ0EB1E102K T 3.1/13.6
C3 4030017690 S.CER ECJ0EC1H121J T 9.1/17.9
C4 4030016790 S.CER ECJ0EB1C103K T 7.9/17.6
C5 4030016790 S.CER ECJ0EB1C103K T 5.5/17
C6 4030017460 S.CER ECJ0EB1E102K T 3.1/15.2
C7 4030017460 S.CER ECJ0EB1E102K T 12.8/17.5
C8 4030016790 S.CER ECJ0EB1C103K T 11.9/17.5
C9 4030017680 S.CER ECJ0EC1H820J T 8.8/16.6
C10 4030017460 S.CER ECJ0EB1E102K T 10/14.7
C11 4030017350 S.CER ECJ0EC1H020B T 10.3/11.9
C51 4030017460 S.CER ECJ0EB1E102K T 18.9/13.8
C53 4030017660 S.CER ECJ0EC1H330J T 15.5/11.1
C54 4030017460 S.CER ECJ0EB1E102K T 14.7/16.4
C55 4030017460 S.CER ECJ0EB1E102K T 17.5/15.7
C56 4030017460 S.CER ECJ0EB1E102K T 19.6/17.7
C57 4030017460 S.CER ECJ0EB1E102K T 12.3/9.3
C58 4030017460 S.CER ECJ0EB1E102K T 14.9/8
C59 4030017650 S.CER ECJ0EC1H270J T 13.9/11.1
C60 4030017420 S.CER ECJ0EC1H470J T 13.4/12.3
C61 4030017520 S.CER ECJ0EC1H0R3B T 12.3/11.1
C62 4030016930 S.CER ECJ0EB1A104K T 19.8/11.8
C63 4030017530 S.CER ECJ0EC1H0R5B T 16.4/11.1
C101 4030017460 S.CER ECJ0EB1E102K T 15.9/1.5
C102 4030017500 S.CER ECJ0EC1H560J T 15.9/2.4
C103 4030017620 S.CER ECJ0EC1H100C T 10.8/1.1
C104 4030017460 S.CER ECJ0EB1E102K T 14/6.5
C105 4030017460 S.CER ECJ0EB1E102K T 17.8/4.4
C106 4030017460 S.CER ECJ0EB1E102K T 19.8/4.5
C107 4030017460 S.CER ECJ0EB1E102K T 7.2/4.7
C108 4030017460 S.CER ECJ0EB1E102K T 8.1/4.7
C109 4030017390 S.CER ECJ0EC1H180J T 10.5/2.5
C110 4030017380 S.CER ECJ0EC1H050B T 10.2/4.7
C111 4030017350 S.CER ECJ0EC1H020B T 10.7/6.8
C112 4030017530 S.CER ECJ0EC1H0R5B T 12.5/1.1
C114 4030017460 S.CER ECJ0EB1E102K T 18/8.6
C115 4030016930 S.CER ECJ0EB1A104K T 18.9/8.6
C116 4030017460 S.CER ECJ0EB1E102K T 19.8/7.7
C117 4030018860 S.CER ECJ0EB0J105K T 19.8/15
C118 4030017640 S.CER ECJ0EC1H150J T 10.2/3.8
C200 4030017460 S.CER ECJ0EB1E102K T 8.4/12.9
C201 4030017460 S.CER ECJ0EB1E102K T 9.1/8.2
C202 4030017460 S.CER ECJ0EB1E102K T 2.4/5.6
C203 4030017460 S.CER ECJ0EB1E102K T 2.3/4.4
C204 4030017460 S.CER ECJ0EB1E102K T 5.3/5.5
C205 4030017460 S.CER ECJ0EB1E102K T 3.2/1.5
C206 4030017460 S.CER ECJ0EB1E102K T 5.6/12.9
C207 4030017460 S.CER ECJ0EB1E102K T 7.2/10.5
C208 4030017460 S.CER ECJ0EB1E102K T 3.1/11.9
C209 4030017380 S.CER ECJ0EC1H050B T 3.3/8.3
C210 4030017380 S.CER ECJ0EC1H050B T 2.4/8.3
C211 4030017360 S.CER ECJ0EC1H030B T 2.7/10.1
C213 4030017590 S.CER ECJ0EC1H070C T 5.5/2.7
J1 6510025380 S.CNR AXK716147G B 4.8/10
