7 - 13
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC1 1180002371 S.REG R1111N321B-TR-F B 30.6/13.6
IC101 1130010920 S.IC AMBE-2020 T 25.4/10.7
IC102 1130011930 S.IC SN74LVC1G04DCKR B 29.9/17.3
IC201 1130012511 S.IC SN74AHC2G74HDCT3 B 18.4/10.5
IC202 1110005430 S.IC CMX589AD5 T 6.3/13.4
IC203 1130011801 S.IC SN74AHC1G66HDBV3 B 6.1/11.7
IC300 1110005290 S.IC NJM2115V-TE1 B 17.5/3.5
IC301 1110005290 S.IC NJM2115V-TE1 B 5.6/16.6
IC350 1130011631 S.IC AD73311ARSZ T 5.9/4.7
Q1 1510000581 S.TR 2SA1362-GR (TE85R F) T 15.2/2.7
Q2 1590003280 S.TR UNR9211J-(TX) T 18/2.2
Q50 1510000581 S.TR 2SA1362-GR (TE85R F) B 26.1/7.9
Q51 1590001170 S.TR XP1501-(TX) AB B 28/3.7
Q100 1530002280 S.TR 2SC4081 T106 S B 26.3/17.3
Q200 1590003390 S.TR UNR9215J-(TX) B 11.3/13.7
Q201 1590003390 S.TR UNR9215J-(TX) B 9.3/13.7
Q202 1530002280 S.TR 2SC4081 T106 S B 19.5/13.7
D100 1790001240 S.DIO MA2S728-(TX) T 26.9/1.6
X100 6050012290 S.XTL CR-820 (16.384 MHz) B 25.3/13.9
X200 6050012300 S.XTL CR-821 (9.8304 MHz) B 15.7/16.6
R1 7030000180 S.RES MCR10EZHJ 22 (220) B 26.1/11.2
R2 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 20.7/1.8
R3 7030005050 S.RES ERJ2GEJ 103 X (10 k) T 17/3.6
R50 7030005040 S.RES ERJ2GEJ 472 X (4.7 k) B 26.2/3.8
R100 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 11.3/2.3
R104 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 31.9/16
R105 7030007280 S.RES ERJ2GEJ 331 X (330) T 12.8/5.8
R106 7030004980 S.RES ERJ2GEJ 101 X (100) B 32.7/18.5
R107 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 28/18.5
R108 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 28.2/16.8
R109 7030004990 S.RES ERJ2GEJ 221 X (220) B 24.1/17.5
R202 7030010040 S.RES ERJ2GEJ-JPW B 15.2/10.1
R203 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 11.7/10.6
R204 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 11.7/11.5
R205 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 11.7/12.4
R206 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 11.7/13.3
R207 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 11.7/14.2
R208 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 23/4.1
R209 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 24.7/2.3
R210 7030005220 S.RES ERJ2GEJ 223 X (22 k) T 2.5/18.6
R211 7030006610 S.RES ERJ2GEJ 394 X (390 k) B 3.3/11.1
R212 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 9.7/11.7
R213 7030004980 S.RES ERJ2GEJ 101 X (100) B 15.9/13
R214 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 17.5/13
R215 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 17.7/14.2
R216 7030004990 S.RES ERJ2GEJ 221 X (220) B 22.4/13.8
R217 7030005050 S.RES ERJ2GEJ 103 X (10 k) B 11.4/11.3
R300 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 21.8/5.7
R301 7030005310 S.RES ERJ2GEJ 124 X (120 k) B 21.8/4
R302 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 17.9/6.2
R303 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 10.1/3.3
R304 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 11.7/2.3
R305 7310004610 S.TRI EVM-2WSX80 B15 (104) T 13.8/18
R306 7030005060 S.RES ERJ2GEJ 333 X (33 k) B 10.4/16.9
R307 7030005090 S.RES ERJ2GEJ 104 X (100 k) B 8.8/18.4
R310 7030005530 S.RES ERJ2GEJ 100 X (10) T 14.3/5
R350 7030005010 S.RES ERJ2GEJ 681 X (680) B 1.7/3.7
R351 7030005120 S.RES ERJ2GEJ 102 X (1 k) B 2.1/8.3
R352 7030005240 S.RES ERJ2GEJ 473 X (47 k) B 6.9/3.8
R353 7030004980 S.RES ERJ2GEJ 101 X (100) B 9.2/3.3
R354 7030005240 S.RES ERJ2GEJ 473 X (47 k) T 11.3/7.1
C1 4550007680 S.TAN TEESVP 0J 226M8R B 28.7/10
C2 4550007600 S.TAN F920J106MPABMA B 30.6/10
C3 4030016930 S.CER ECJ0EB1A104K B 33.2/13.3
C50 4030017460 S.CER ECJ0EB1E102K B 26.3/2.2
C51 4030017460 S.CER ECJ0EB1E102K B 25.3/4.7
C52 4550006930 S.TAN TEESVP 0J 225M8R B 29.6/5.9
C53 4030017460 S.CER ECJ0EB1E102K B 30.3/3.5
C54 4030017460 S.CER ECJ0EB1E102K B 24.2/5.9
C100 4030016930 S.CER ECJ0EB1A104K T 18.7/18.7
C101 4030016930 S.CER ECJ0EB1A104K B 21.7/15.8
C102 4030016930 S.CER ECJ0EB1A104K B 33.2/10.1
C103 4030016930 S.CER ECJ0EB1A104K T 32.5/19.2
C104 4030016930 S.CER ECJ0EB1A104K T 33.2/3.6
C106 4030016930 S.CER ECJ0EB1A104K T 16.3/10.9
C107 4030016930 S.CER ECJ0EB1A104K T 16/7.6
C108 4030016930 S.CER ECJ0EB1A104K B 20.2/8.3
C109 4030016930 S.CER ECJ0EB1A104K T 22.8/1.5
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C110 4030017420 S.CER ECJ0EC1H470J B 29.1/7.3
C111 4030017460 S.CER ECJ0EB1E102K B 22.9/16.2
C112 4030016930 S.CER ECJ0EB1A104K B 26.4/19
C113 4030016930 S.CER ECJ0EB1A104K B 24.1/18.4
C114 4030016930 S.CER ECJ0EB1A104K B 27.8/14.2
C116 4030016930 S.CER ECJ0EB1A104K B 31.8/18.5
C117 4030017460 S.CER ECJ0EB1E102K B 24.1/16.6
C200 4030017460 S.CER ECJ0EB1E102K B 18.2/15.9
C201 4030016930 S.CER ECJ0EB1A104K B 16.8/14.2
C202 4030016930 S.CER ECJ0EB1A104K B 21.2/13.5
C203 4030016930 S.CER ECJ0EB1A104K B 13/17.5
C204 4030017460 S.CER ECJ0EB1E102K B 17.8/8.3
C205 4030016930 S.CER ECJ0EB1A104K T 12.1/15.7
C206 4030017030 S.CER ECJ0EB1A273K B 2.3/18.4
C207 4030017030 S.CER ECJ0EB1A273K T 2.5/17.7
C208 4030016930 S.CER ECJ0EB1A104K B 2.9/12.3
C209 4030017400 S.CER ECJ0EC1H220J B 24.7/3.2
C210 4030018860 S.CER ECJ0EB0J105K T 11.2/15.7
C211 4030017460 S.CER ECJ0EB1E102K B 11.3/15.2
C212 4030017760 S.CER ECJ0EB1H222K T 11.1/18.8
C213 4030016930 S.CER ECJ0EB1A104K B 5.2/13.9
C214 4030017460 S.CER ECJ0EB1E102K B 7.5/13.9
C216 4030017460 S.CER ECJ0EB1E102K B 19.1/15.9
C300 4030016930 S.CER ECJ0EB1A104K B 23/2.3
C301 4030018860 S.CER ECJ0EB0J105K B 18.9/7.1
C302 4030016930 S.CER ECJ0EB1A104K B 10/4.9
C303 4030016930 S.CER ECJ0EB1A104K B 9.9/15.7
C304 4030017490 S.CER C1608 JB 1A 105K-T B 2.2/14
C310 4550007730 S.TAN TEESVJ 0J 106M8R B 3/5.9
C350 4030016930 S.CER ECJ0EB1A104K B 2.1/9.2
C351 4030016970 S.CER ECJ0EB1C223K B 1.7/4.6
C352 4030016950 S.CER ECJ0EB1A473K B 8.7/4.9
C353 4030016930 S.CER ECJ0EB1A104K B 2.8/2.8
C354 4030016930 S.CER ECJ0EB1A104K B 2.8/1.9
C355 4030017420 S.CER ECJ0EC1H470J T 13/2.7
C356 4550006930 S.TAN TEESVP 0J 225M8R B 7.2/2.4
C357 4030016930 S.CER ECJ0EB1A104K B 9.6/1.8
C358 4030016930 S.CER ECJ0EB1A104K B 4.7/4.2
C360 4030017460 S.CER ECJ0EB1E102K B 5/1.4
J1 6510025550 S.CNR AXK824125WG B 10.8/8.2
EP1 6910015370 S.BEA ACZ1005Y-102-T B 33.2/11.7
EP100 6910015370 S.BEA ACZ1005Y-102-T B 33.2/15.8
EP200 6910015370 S.BEA ACZ1005Y-102-T B 13/15.9
EP201 6910015370 S.BEA ACZ1005Y-102-T B 15/12
EP202 6910015370 S.BEA ACZ1005Y-102-T T 13.7/15.4
EP203 6910015370 S.BEA ACZ1005Y-102-T B 8.8/11.7
EP300 6910015370 S.BEA ACZ1005Y-102-T B 23/3.2
EP350 6910015370 S.BEA ACZ1005Y-102-T B 4/6.3
EP351 6910015370 S.BEA ACZ1005Y-102-T B 6.2/5.6
EP352 6910015370 S.BEA ACZ1005Y-102-T T 11.3/3.4
• UT-121 (Optional product; [CODEC UNIT] for IC-91AD)
