Icom IC-F211 - Advanced Key Operations

• SCAN START/STOP KEY
Push this key to start scanning; and push again to
stop.
NOTE: Place the microphone on hook to start
scanning.
Take the microphone off hook to stop scanning.
• SCAN TAG KEY
TAG
Adds or deletes the selected channel to the scan
group.
• PRIORITY CHANNEL KEYS
Push these keys to select priority A or priority B
channel, respectively.
• OPERATING CHANNEL KEYS
MR-1
MR-2
MR-3
MR-4
Select an operating channel directly.
• MONITOR KEY
MONI
Activates one of (or two of) the following functions
on each channel independently:
• Push and hold the key to unmute the channel (audio is
emitted; ‘Audible’ condition).
• Push the key to toggle between the mute and unmute
conditions (toggles between ‘Audible’ and ‘Inaudible’).
• Push the key to mute the channel (sets to ‘Inaudible’
only).
• Push the key to unmute the channel (sets to ‘Audible’
only).
• Push the key after communication is finished to send a
‘reset code’.
NOTE: The unmute condition (‘Audible’ condi-
tion) may automatically return to the mute con-
dition (‘Inaudible’ condition) after a specified
period depending on the pre-setting.
• LOCK KEY
LOCK
Push this key for 1 sec. to lock all programmable
keys except the following:
• [ CALL ] (incl. [CAL A] and [CAL B]), [ MONI ] and
[ EMER ] keys.
4
1
PANEL DESCRIPTION
