33
6
BATTERY CASE
5
6
Optional battery case (BP-240)
■
When using the optional battery case attached to the trans-
ceiver, install 6 × AAA (LR03) size alkaline batteries as illus-
trated at right.
Unhook the battery cover release hook ( q q), and open the
cover in the direction of the arrow (w). (Fig.1)
Then, install 6 w × AAA (LR03) size alkaline batteries.
(Fig.2)
• Install the alkaline batteries only.
• Be sure to observe the correct polarity.
Fit the cover in the direction of the arrow ( e e), then close
(r). And hook the battery cover release hook until it makes
a ‘click’ sound (t). (Fig.3)
CAUTION:
• When installing batteries, make sure they are all the
same brand, type and capacity. Also, do not mix new and
old batteries together.
• Keep battery contacts clean. It’s a good idea to clean bat-
tery terminals once a week.
• Never incinerate used battery cells since internal battery
gas may cause them to rupture.
•
Never expose a detached battery case to water. If the bat-
tery case gets wet, be sure to wipe it dry before using it.
NOTE: When the optional battery case is attached, the
battery type must be selected to “DRY BATT” when turning
the transceiver ON. ((☞ p. 11))
q
BP-240
w
Fig.1
Fig.2
Fig.3
e
r
t
