Icom IC-F8101 Instruction Manual

16
3
RECEIVE AND TRANSMIT
2001 NEW 2001 NEW
■ Functions for receive (Continued)
D AGC function
The AGC (automatic gain control) controls receiver
gain to produce a constant audio output level, even
when the received signal strength varies by fading,
and so on.
The transceiver has two AGC characteristics, AUTO
and time constants FAST and SLOW.
[Default]
/
q Push [8] to enter the Main Menu screen.
w Select the “AGC” item of “Setmode.”
q Push [r] or [s] to select the item, and then
push [4] to open the screen.
(Setmode > Config)
w Push [r] or [s] to select “AGC,” and then hold
down [4] for 1 second.
e Push [r] or [s] to select the desired option, FAST,
SLOW or AUTO.
• If desired, hold down [Default](§§) for 1 second to re-
turn to the default setting
.
When AUTO is selected, the AGC time constant
varies, depending on the operating mode.
r Push [4] to save the setting, and return to the pre-
vious screen.
t Push [8] one or more times to exit.
D AGC OFF function
When receiving weak signals with adjacent strong
signals or noise, the AGC function may reduce the
sensitivity. In this situation, the AGC function should
be turned OFF.
[Default]
/
q Push [8] to enter the Main Menu screen.
w Select the “AGC” item of “Setmode.”
q Push [r] or [s] to select the item, and then
push [4] to open the screen.
(Setmode > Config)
w Push [r] or [s] to select “AGC,” and then hold
down [4] for 1 second.
e Push [r] or [s] to turn OFF the function.
• If desired, hold down [Default](§§) for 1 second to re-
turn to the default setting
.
r Push [4] to save the setting, and return to the pre-
vious screen.
t Push [8] one or more times to exit.
