1V4.01– A-7264-2EX
iF8101
CI-V information— Ver. 4.01 or later
This information is discribed using Version 4.01 or later firmware. Earlier versions are some different.
Controller to IC-F8101
FE FE 8A E0 Cn Sc Data area FD
Preamble
code (fixed)
Transceiver’s
default address
Controller’s
default address
Command number
(see the command table)
Sub command number
(see the command table)
BCD code data such as
for frequency, memory
number entry
(see the data content description)
End of message
code
(fixed)
OK message to controller
FE FE E0 8A FB FD
FE FE E0 8A FA FD
Preamble
code (fixed)
Controller’s
default address
Transceiver’s
default address
OK code
(fixed)
End of message
code
(fixed)
NG message to controller
NG code
(fixed)
IC-F8101 to controller
q we r t y u
FE FE E0 8A Cn Sc Data area FD
q we r t y u
The transceiver can be connected to a PC with a USB
cable. The Icom Communications Interface-V (CI-V)
controls the transceiver.
• A USB cable (A-B type, user supplied)
The required USB driver and driver install guide can be
downloaded from the Icom web site.
GO to “http://www.icom.co.jp/world,” then click “Support,”
“Firmware Updates / Software downloads” in sequence.
* The download procedure on the web page may
change without notice.
The CI-V system can be operated using the following
data formats. Data formats differ, depending on
command numbers. A data area or sub command is
added for some commands.
CI-V connection
Data format
