Icom IC-F8101 Instruction Manual

2V4.01– A-7264-2EX
Cmd.
Sub
cmd.
Set mode
Data Description
Category Item
02 See
p. 6
Read the upper and lower
frequencies
03 See
p. 6
Read the operating frequency
07 Select the VFO mode
00 Select VFO A
01 Select VFO B
08 Select the Memory mode
0E 00 Scan stop
01 Scan start
14 01 See
p. 6
Send/read the AF level
(0000=min. to 0255=max.)
15 01 00 Read the squelch status
(squelch closed)
01 Read the squelch status
(squelch open)
02 0000
to
0255
Read the S-meter level
( 0000=0, 0051=1, 0102=2, 0153=3,
0204=4, 0255=5)
11 0000
to
0255
Read the Power meter level
( 0000=0, 0051=1, 0102=2, 0153=3,
0204=4, 0255=5)
16 40 00 Send/read Noise Reduction OFF
01 Send/read Noise Reduction ON
1A 05 00 00 00 to
30
Send/read the LQA Decay setting
( 00=Disable,
01 to 30=1 to 30 days)
01 00 to
48
Send/read the BER Threshold level
( 00 to 48=0 to 48)
02 00 to
03
Send/read the Golay Threshold level
(00 to 03=1 to 3)
03 00 to
04
Send/read the Error Threshold level
(00 to 04=0 to 4)
04 00/01 Send/read the Silent setting
(00=OFF, 01=ON)
05 00 to
10
Send/read the Call Retry setting
(00=0 (OFF), 01 to 10=1 to 10)
06 01 to
08
Send/read the LQA Average setting
( 01 to 08=1 to 8)
07 00/01 Send/read the LQA Request setting
(00=OFF, 01=ON)
08 00/01 Send/read the AMD Position setting
( 00=Calling frame,
01=Acknowledgement frame)
01 00 00 to
50
Send/read the Beep Level
( 00=OFF, 01 to 50=1 to 50)
01 00 to
50
Send/read the Ringtone Level
( 00=OFF, 01 to 50=1 to 50)
02 00 to
05
Send/read the CW Side Tone Level
( 00=OFF, 01 to 50=1 to 50)
02 00 00/01 Send/read the Accept Icom Selcall
setting (00=OFF, 01=ON)
• This is permanently set to ON.
01 00/01 Send/read the Accept Open Selcall
setting (00=OFF, 01=ON)
• This is permanently set to ON.
02 00/01 Send/read the Accept ALE setting
(00=OFF, 01=ON)
• This is permanently set to ON.
Cmd.
Sub
cmd.
Set mode
Data Description
Category Item
1A 05 02 03 00/01 Send/read the Accept RFDS setting
(00=OFF, 01=ON)
• This is permanently set to ON
for AUS version, or OFF for other
versions.
04 00/01 Send/read the TX Open STUN Call
setting
(00=OFF, 01=ON)
05 02 to
60
Send/read the RX Timeout timmer
(02 to 60=2 to 60 seconds)
06 00 to
02
Send/read the Auto Start Type
setting
(00=OFF, 01=Scan, 02=Termination)
07 01 to
26
Send/read the Auto Start Wait Time
setting
( 01 to 05=1 to 5 seconds,
06 to 25=1 to 20 minutes,
26=INFINITE)
03 00 00 to
50
Send/read the Meter Squelch Level
( 00 to 50=0 to 50)
01 00/01 Send/read the Noise Blanker setting
(00=OFF, 01=ON)
02 00 to
15
Send/read the Noise Blanker Level
(00 to 15=0 to 15)
03 00 to
09
Send/read the Noise Blanker Depth
(00 to 09=0 to 9)
04 00 to
15
Send/read the Clear Talk Level
( 01 to 15=1 to 15)
05 00 to
02
Send/read the Preamplier or
Attenuator setting
( 00=(Preamp) ON, 01=OFF,
02=ATT ON)
06 00 to
03
Send/read the AGC setting
( 00=OFF, 01=FAST, 02=SLOW,
03=AUTO)
07 00 to
02
Send/read the RF Power setting
( 00=LOW, 01=MID, 02=HIGH)
08 00/01 Send/read the Fan setting
(00=AUTO, 01=CONTINUOUS)
09 00/01 Send/read the Speech Processor
setting
( 00=OFF, 01=ON)
10 00 to
10
Send/read the Speech Processor
Level
( 00 to 10=0 to 10)
11 00 to
10
Send/read the Mic Gain
(00 to 10=0 to10)
12 00 to
04
Send/read the TX Timeout setting
( 00=OFF, 01=1 min., 02=3 min.,
03=5 min., 04 =10 min.)
13 00 to
04
Send/read the CW Break-in setting
( 00=OFF, 01=0.5, 02=1, 03=2,
04=3 seconds)
14 00/01 Send/read the Tuner setting
( 00=OFF, 01=ON)
15 00/01 Send/read the PTT Tune setting
( 00=OFF, 01=ON)
16 00/01 Send/read the VFO Mode
availability
(00=OFF, 01=ON)
17 00/01 Send/read the VFO Split setting
(00=OFF, 01=ON)
Command table
