Icom IC-M25 Service Manual

8-1
[CHASSIS PARTS]
REF ORDER
DESCRIPTION QTY.
NO. NO.
MP1 8210031130 3723 FRONT PANEL ASSEMBLY [USA] 1
8210031130 3723 FRONT PANEL ASSEMBLY [EXP] 1
8210031100 3723 FRONT PANEL ASSEMBLY (A) [EUR] 1
8210031100 3723 FRONT PANEL ASSEMBLY (A) [UK] 1
8210031100 3723 FRONT PANEL ASSEMBLY (A) [FRG] 1
8210031100 3723 FRONT PANEL ASSEMBLY (A) [HOL] 1
8210031100 3723 FRONT PANEL ASSEMBLY (A) [AUS] 1
8210031110 3723 FRONT PANEL (B) ASSEMBLY WT [USA-01] 1
8210031110 3723 FRONT PANEL (B) ASSEMBLY WT [EXP-01] 1
8210031080 3723 FRONT PANEL (B) A WT [EUR-01] 1
8210031080 3723 FRONT PANEL (B) A WT [UK-01] 1
8210031080 3723 FRONT PANEL (B) A WT [FRG-01] 1
8210031080 3723 FRONT PANEL (B) A WT [HOL-01] 1
8210031080 3723 FRONT PANEL (B) A WT [AUS-01] 1
8210031120 3723 FRONT PANEL (A) ASSEMBLY BU [USA-02] 1
8210031120 3723 FRONT PANEL (A) ASSEMBLY BU [EXP-02] 1
8210031090 3723 FRONT PANEL (A) A BU [EUR-02] 1
8210031090 3723 FRONT PANEL (A) A BU [UK-02] 1
8210031090 3723 FRONT PANEL (A) A BU [FRG-02] 1
8210031090 3723 FRONT PANEL (A) A BU [HOL-02] 1
8210031090 3723 FRONT PANEL (A) A BU [AUS-02] 1
J31 6910021491 ANT CONNECTOR 106-1 <SSC> 1
W2 8920001430 CAB-1185 1
EP1 0800014740 BP-282 EU 1
MP8 8930083240 COIL SPRING (AM) 1
MP9 8930092200 3723 SHAFT M5K 1
MP10 8110010830 3723 USB COVER 1
MP11 8930092150 3723 USB SEAL (TOP) 1
MP12 8930092090 3723 RELEASE BUTTON 1
MP13 8930092230 3723 SPRING M5K 1
MP14 8850003421 SEALING WASHER (AA)-1 (TOT) 1
MP15 8830003440 3285 ANT NUT 1
MP16 8930092080 3723 MIC CAP 1
MP17 8930092070 3723 CAP HOLDER 1
MP18 8930078010 3168 MIC SEAL (TOT) 1
MP21 8210030940 3723 REAR PANEL 1
MP22 8930092140 3723 MAIN SEAL (TOP) 1
MP24 8820001510 3062 SCREW 6
MP25 8930063690 O-RING (BA) (TOP) 6
MP31 8010023460 3723 CHASSIS 1
MP33 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0) 5
MP42 8810008751 PHBT M2 X15 NI-ZK3 1
MP43 8810009181 BT M2 X 5 NI-ZC3 5
MP48 8930030920 1301 SHEET 1
MP50 8930071260 O-RING (BL) (TOP) 1
MP51 8930092190 3723 DETECTION PIN (M5K) 1
MP57 8930057950 DOUBLE SIDE TAPE (AH) 2
MP58 8930085980 SHIELD TAPE (Z) 1
MP59 8930092640 THERMAL SHEET (CW) TC300CAS10 (10X15) 1
MP60 8930092180 THERMAL SHEET (CT) TC200CAS (5X14.5) 1
MP61 8930092380 3723 EARTH SPRING Y1355 [EUR] 1
8930092380 3723 EARTH SPRING Y1355 [UK] 1
8930092380 3723 EARTH SPRING Y1355 [FRG] 1
8930092380 3723 EARTH SPRING Y1355 [HOL] 1
8930092380 3723 EARTH SPRING Y1355 [EUR-01] 1
8930092380 3723 EARTH SPRING Y1355 [UK-01] 1
8930092380 3723 EARTH SPRING Y1355 [FRG-01] 1
8930092380 3723 EARTH SPRING Y1355 [HOL-01] 1
8930092380 3723 EARTH SPRING Y1355 [EUR-02] 1
8930092380 3723 EARTH SPRING Y1355 [UK-02] 1
8930092380 3723 EARTH SPRING Y1355 [FRG-02] 1
8930092380 3723 EARTH SPRING Y1355 [HOL-02] 1
[ACCESSORIES]
[MAIN UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J251* 6510021901 BM02B-ASRS-TF (LF) (SN) 1
J252* 6510022692 06FLT-SM2-TB (LF) (SN) (M) 1
J601* 6510030040 CSS5005-4R11F 1
J603* 6510030990 BM03B-AUHKS-GA-TB (LF) (SN) 1
J604* 6510025142 10FLT-SM2-TB (LF) (SN) (M) 1
DS246 5030003980 TJ3901TF <VKHK> 1
MC250 7700002900 EM6027P-38C33-G <HOR> 1
S1* 2260003300 EVQPQHB55 1
S2* 2260003300 EVQPQHB55 1
S3* 2260003300 EVQPQHB55 1
S4* 2260003300 EVQPQHB55 1
S5* 2260003300 EVQPQHB55 1
S6* 2260003300 EVQPQHB55 1
S7* 2260003300 EVQPQHB55 1
S8* 2260003300 EVQPQHB55 1
S9* 2230001071 JPM1990-2712EC 1
EP360 8930092270 SRCN-3723-SP-N-W (SHJ) 1
MP20* 8510014940 2601 VCO CASE Y641 1
MP21 8510014950 2601 VCO COVER Y642 1
MP100 8930085111 SHIELD SPONGE (CX)-1 1
MP360 8210030990 3723 REFLECTOR M5K 1
MP361 8930092160 3723 LCD HOLDER Y1350 1
MP363 8930092240 3723 WHITE SHEET 1
MP365 8930085120 SHIELD TAPE (Y) 1
MP366 8930083320 SPONGE (LH) 1
REF ORDER
DESCRIPTION QTY.
NO. NO.
EP1 (Optional) FA-SC59V 1
EP2 5930002030 BC-217SA <SLVJ> [USA] 1
5930002040 BC-217SE <SLVJ> [EXP] 1
5930002040 BC-217SE <SLVJ> [EUR] 1
5930002040 BC-217SE <SLVJ> [FRG] 1
5930002040 BC-217SE <SLVJ> [HOL] 1
5930002050 BC-217SV <SLVJ> [AUS] 1
5930002030 BC-217SA <SLVJ> [USA-01] 1
5930002040 BC-217SE <SLVJ> [EXP-01] 1
5930002040 BC-217SE <SLVJ> [EUR-01] 1
5930002040 BC-217SE <SLVJ> [FRG-01] 1
5930002040 BC-217SE <SLVJ> [HOL-01] 1
5930002050 BC-217SV <SLVJ> [AUS-01] 1
5930002030 BC-217SA <SLVJ> [USA-02] 1
5930002040 BC-217SE <SLVJ> [EXP-02] 1
5930002040 BC-217SE <SLVJ> [EUR-02] 1
5930002040 BC-217SE <SLVJ> [FRG-02] 1
5930002040 BC-217SE <SLVJ> [HOL-02] 1
5930002050 BC-217SV <SLVJ> [AUS-02] 1
EP6 6910018620 BLACK HANDY STRAP <TOM> 1
MP2 (Optional) MB-133 1
[MIC UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J250 6450002460 HSJ1594-010160 1
J607* 6510025142 10FLT-SM2-TB (LF) (SN) (M) 1
J608 6510009351 B2B-ZR (LF) (SN) 1
S250 2260001900 SW-149 (SKHLLDA010) 1
W1 8900014801 OPC-1573-1 (P0.5N10L50) 1
SECTION 8
.
MECHANICAL PARTS
*Refer to “BOARD LAYOUTS” for the location.
**Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

Icom IC-M25 Specifications

General

Battery type	BP-282
Battery life (max)	11 h
Battery low indication	Yes
Number of batteries supported	1
Purpose	Marine Radio Service
Operating frequency	156.025 - 157.425 MHz
Display type	LCD
USB connector type	Micro-USB B
Antenna connector type	FA-SC59V
Product color	Black, White
Waterproof up to	1 m
International Protection (IP) code	IPX7
Operating temperature (T-T)	-20 - 60 °C
Number of batteries included	1 pc(s)

Weight and Dimensions

Depth	30.5 mm
Width	56.6 mm
Height	134.2 mm
Weight	220 g
