BATTERY CHARGING
■ Optional battery charger
D BC-162 installation
Supplied screwsSupplied screws
• To a desktop • To a wall
• For added stability
Eyelet:
Use a rubber band to
secure the transceiver,
if desired.
D Charging
q Connect the power adapter as shown below.
w Insert the battery pack with/without the transceiver into
the charger.
• The charge indicator lights orange.
• The charge indicator blinks orange (or red) when the protector
is activated.
e Charge the battery pack approx. 2 hours, depending on
the remaining power condition.
• The charge indicator lights green when charging is completed.
NOTE: The battery charger, BC-162, has a charging
timer. The timer stops the charging process after 4
hours (approx.).
BC-162
Charge
indicator
Tu rn power OFF
Battery pack Transceiver
Power adapter
(Not supplied with
some versions)
