SPECIFICATIONS
12
D GENERAL
• Frequency coverage : Transmit 156.000–161.450 MHz
Receive 156.000–163.425 MHz
• Mode : FM (16K0G3E)
• Channel spacing : 25 kHz
• Power supply requirement : BP-251 and BP-252 only
• Current drain (at 7.4 V DC)
TX at 6 W : 1.5 A typical
at 5 W : 1.3 A typical
at 1 W : 0.7 A typical
at 0.5 W : 0.6 A typical
RX Max. audio
Internal speaker : 0.3 A typical
External speaker : 0.2 A typical
Power save : 10 mA typical
• Frequency stability : ±1.5 kHz
• Operating temperature range : –15°C to +55°C
• Dimensions : 62 (W) × 139.5 (H) × 43 (D) mm
(Projections not included)
• Weight : Approx. 295 g
(incl. BP-252, FA-SC58V and MB-109)
D TRANSMITTER
• Output power (at 7.4 V DC) : 6 W (High) and 1 W (Low)*
*
5 W (High) and 1 W (Low) for Australian
version
1 W (High) and 0.5 W (Low) for German
version depending on the pre-setting
• Modulation system : Variable reactance frequency
modulation
• Maximum frequency deviation : ±5 kHz
• Adjacent channel power : 70 dB
• Spurious emissions : 0.25 µW
D RECEIVER
• Receive system : Double-conversion superhetero-
dyne
• Sensitivity (20 dB SINAD) : –2 dBµ emf typical
• Squelch sensitivity : –6 dBµ emf typical (at threshold)
• Intermodulation : 68 dB
• Spurious response : 70 dB*
*
65 dB for Australian version
• Adjacent channel selectivity : 70 dB
• Audio output power (at 10% distortion)
Internal speaker : 0.7 W typical with a 16 Ω load
External speaker : 0.2 W with an 8 Ω load
All stated specifications are subject to change without notice or obligation.
