SPECIFICATIONS AND OPTIONS
■ Specifications
• GENERAL
Frequency coverage : Transmit 156–157.5 MHz
Receive 156–163 MHz
Mode : FM (16K0G3E)
Channel spacing : 25 kHz
Current drain (at 7.2 V) : TX High (5 W) 1.6A typical.
Max. audio 230 mA typical
Standby 60 mA typical
Power saved 20 mA typical
Frequency stability : ±10 ppm (–20°C to +60°C)
Useable temperature range: –20°C to +60°C; –4°F to +140°F
Dimensions : 58 (W) × 140.5(H) × 43.5(D) mm
(Projections not included) 2.3 (W) × 5.5 (H) × 1.7 (D) in
Weight : 410g (14.4 oz)
• TRANSMITTER
Output power (at 7.2 V) : 5 W and 1 W
Modulation system : Variable reactance phase modu-
lation
Max. frequency deviation : ±5.0 kHz
Spurious emissions : Less than –65 dB
• RECEIVER
Receive system : Double-conversion superhetero-
dyne
Sensitivity (12 dB SINAD) : 0.25 µV typical
Squelch sensitivity: Threshold Less than 0.35 µV
Tight Less than 2.00 µV
Intermodulation rejection ratio : 70 dB typical
Spurious response rejection ratio : 70 dB typical
Adjacent channel selectivity : 70 dB typical
Audio output power : 500 mW at 10% distor-
tion with an 8 Ω load
All stated specifications are subject to change with-
out notice or obligation.
■ Options
• CP-12L CIGARETTE LIGHTER CABLE WITH NOISE FILTER
Connects to a ship’s or vehicle’s cigarette lighter socket
(12V).
• OPC-254L DC POWER CABLE
Used for charging with an external power supply.
• BP-204 BATTERY CASE
Battery case for R6(AA) × 6 alkaline or Ni-Cd cells.
• BC-110D/V AC ADAPTER
Regulary charge battery packs attached to the transceiver in
15 to 20 hrs. BC-110D for Europe (AC 230 V), BC-110V for
Australia (AC 240 V).
