TM 10-7360-226-13&P
CONTAINERIZED KITCHEN (CK) 0018 00
UNIT MAINTENANCE PROCEDURES
0018 00-4
Figure 3. Air Conditioner Terminal Boards.
Generator Set:
Refer to the troubleshooting procedures in TM 9-6115-642-24 to test the generator set.
REPLACE
Before servicing any component of the mechanical room, turn OFF and
tag or lock the required circuit breaker on the Power Distribution Panel.
Ensure all power is off to the component being serviced.
Power Entrance Panel: See WP 0026 00.
MBU Converter: Unplug the converter from its 115 VAC receptacle. Disconnect the 24 VDC
output power connectors. Remove the mounting hardware and replace the converter. Reinstall
hardware and connectors. Plug the converter power cable into the designated 115 VAC
receptacle.
GROUND
CONDENSER BLOWER HIGH
CONDENSER BLOWER LOW
UNUSED
EVAPORATOR BLOWER HIGH
EVAPORATOR BLOWER LOW
COMPRESSOR 2
COMPRESSOR 1
12 VDC
UNUSED
Air conditioner – Unit 2
(Top Air Conditioner)
Air conditioner – Unit 1
(Bottom Air Conditioner)
GROUND
CONDENSER BLOWER HIGH
CONDENSER BLOWER LOW
HEATER RELAY
EVAPORATOR BLOWER HIGH
EVAPORATOR BLOWER LOW
COMPRESSOR 2
COMPRESSOR 1
12 VDC
UNUSED
