TM 10-7360-226-13&P
CONTAINERIZED KITCHEN (CK) 0014 00
TROUBLESHOOTING PROCEDURES (KITCHEN APPLIANCES)
0014 00-1
THIS WORK PACKAGE COVERS
Kitchen Appliances
INITIAL SETUP:
CK set up
Maintenance Level
Operator/Crew
KITCHEN APPLIANCE MALFUNCTIONS
Table 1. Troubleshooting Procedures (Kitchen Appliances)
Malfunction Test or Inspection Corrective Action
Refrigerator does not
operate
Power cord plugged in Plug in power cord
Refrigerator receptacle circuit
breaker tripped
Check/reset circuit breaker (#7
or #9 on Power Distribution
Panel)
Thermostat turned off Turn on/adjust thermostat
Notify unit maintenance
Refrigerator operates
but does not cool
Thermostat setting too high Adjust thermostat to colder
setting
Obstructed air flow at base of unit Clear airflow obstructions
Refrigerator door not sealed Reclose door
Inspect door gasket for tears, cuts,
or other damage
Notify unit maintenance
Mobile warming cabinet
does not heat
Power cord plugged in Plug in power cord
Warming cabinet receptacle circuit
breaker tripped
Check/reset circuit breaker (#16
on Power Distribution Panel)
Check temperature setting (at
bottom front of cabinet)
Adjust temperature setting (at
bottom front of cabinet)
Notify unit maintenance
