TM 10-7360-226-13&P
CONTAINERIZED KITCHEN (CK) 0005 00
DESCRIPTION OF OPERATOR CONTROLS AND INDICATORS
0005 00-4
GENERATOR
POWER
AVAILABLE
OFF
EXTERNAL
POWER
AVAILABLE
EXTERNAL
POWER ON
GENERATOR
POWER ON
ON
OFF
ON
OFF
NORMAL
BLACKOUT
INTERIOR
LIGHTING
LIGHTING
MODE
EMERGENCY
LIGHT
SYSTEM POWER SELECTION
E-STOP
Figure 3. Main Control Panel.
MODERN BURNER UNIT (MBU)
MBU Power Switch
The MBU POWER switch, Figure 4, is located on the wall in the food preparation area, next to
the spice rack. It is an ON/OFF toggle switch that controls the 110 VAC receptacle in the
mechanical room that the MBU converter plugs into. Placing the switch in OFF shuts down all
operating MBUs.
