TM 10-7360-226-13&P
CONTAINERIZED KITCHEN (CK) 0006 00
OPERATION UNDER USUAL CONDITIONS
0006 00-10
Figure 8. Arch Spacer Installation.
12. Install a curved spacer, as shown in Figure 9, over each serving wing door. Place one end
of the spacer near the down-turn of the roof arch and lift up the other end against the fabric.
Force the roof fabric up until the end of the spacer fits over the next arch. Position the
spacers approximately 2 feet in from the doors. If desired, the doors can be held open by
folding them up and wedging them between the fabric and the curved spacers.
Figure 9. Doorway Support Installation.
