Icom IC-M72

6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R415 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
[scramble] only B 32/18.6
R416 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
[scramble] only B 63.8/4.2
R417 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
[scramble] only B 62.9/5.1
R419 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
[scramble] only B 36.8/20
R430 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 10.2/33
R431 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 11.7/33.9
R432 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 14.8/32.2
R433 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 11.8/6.8
R434 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 10.5/5.5
R435 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
)
B 6.7/2.7
R436 7030006610 S.RES ERJ2GEJ 394 X (390 k
)
B 7.7/2.7
R437 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 7.7/4.3
R438 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
)
B 7.7/5.6
R439 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 13.8/6.8
R440 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
)
B 13.7/5.5
R441 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 16.3/6.7
R442 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 12.1/5.5
R450 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
B 26.4/25.8
R451 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
)
B 28/25.4
R452 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
B 29.3/25.4
R453 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 28/26.3
R454 7030005170 S.RES ERJ2GEJ 474 X (470 k
)
Except [AUS] only B 29.2/28.2
R481 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 85/25.8
R483 7030005530 S.RES ERJ2GEJ 100 X (10) B 85/27.4
R489 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 72.9/25.3
R491 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 78.3/24.9
R493 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 76.4/25.5
R495 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 78.3/23.9
R496 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 79.5/22.7
R497 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 80.5/21.5
R498 7030009150 S.RES ERJ2GEJ 824 X (820 k
)
B 79.3/6.3
R499 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
)
B 80.9/7.1
R500 7030007060 S.RES ERJ2GEJ 684X (680 k
)
B 82/5.9
R501 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 81.1/5.9
R502 7030010040 S.RES ERJ2GEJ-JPW [scramble] only B 72.9/26.2
R505 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 64.8/18.6
R512 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
[scramble] only B 66/3
R520 7030010040 S.RES ERJ2GEJ-JPW B 10.4/38.9
R521 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
)
Except [AUS] B 11.3/38.9
7030010040 S.RES ERJ2GEJ-JPW [AUS] B 11.3/38.9
R540 7030005700 S.RES ERJ2GEJ 274 X (270 k
)
B 27.2/10.2
R541 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 27.8/6.9
C160 4030018240 S.CER ECJ0EB1E562K B 50.3/23
C170 4030017460 S.CER ECJ0EB1E102K B 51.3/38.1
C171 4030017680 S.CER ECJ0EC1H820J B 52.3/27.9
C174 4030017460 S.CER ECJ0EB1E102K B 54.6/28.3
C175 4030017460 S.CER ECJ0EB1E102K B 56.1/26.3
C176 4030017460 S.CER ECJ0EB1E102K B 54.9/27.1
C177 4030016930 S.CER ECJ0EB1A104K B 50.1/38.9
C178 4030018890 S.CER ECJ0EB0J224K B 50.1/37.9
C179 4030017450 S.CER ECJ0EB1E271K B 53.1/38.1
C180 4030017450 S.CER ECJ0EB1E271K B 54.9/38.1
C181 4030016930 S.CER ECJ0EB1A104K B 52.2/37.3
C200 4030016790 S.CER ECJ0EB1C103K B 19.9/33.5
C202 4030016930 S.CER ECJ0EB1A104K B 22.4/25.9
C205 4030016960 S.CER ECJ0EB1C183K B 19.8/28.6
C206 4030017460 S.CER ECJ0EB1E102K B 19.8/26.8
C207 4030016930 S.CER ECJ0EB1A104K B 21.1/25.4
C222 4030016790 S.CER ECJ0EB1C103K B 28.3/16.7
C224 4550006250 S.TAN TEESVA 1A 106M8R B 28.3/21.7
C225 4030018890 S.CER ECJ0EB0J224K B 23.4/17.3
C226 4030016790 S.CER ECJ0EB1C103K B 21.6/14.5
C227 4550006250 S.TAN TEESVA 1A 106M8R B 20.8/16.1
C228 4030017460 S.CER ECJ0EB1E102K B 23.2/14.5
C229 4030017460 S.CER ECJ0EB1E102K B 26.2/6.7
C230 4550006470 S.TAN TEESVB2 1D 106M8R B 23.8/8.9
C231 4030018870 S.CER ECJ0EF0J105Z B 31.8/5.5
C233 4030016790 S.CER ECJ0EB1C103K B 30.7/16.6
C240 4030017460 S.CER ECJ0EB1E102K B 27.2/8.6
C250 4030016790 S.CER ECJ0EB1C103K [AUS] B 6.5/36.3
4030016930 S.CER ECJ0EB1A104K Except [AUS] B 6.5/36.3
C251 4550006250 S.TAN TEESVA 1A 106M8R B 12.9/39.2
C252 4030017460 S.CER ECJ0EB1E102K B 10.4/40.5
C254 4030016790 S.CER ECJ0EB1C103K B 21/37.5
C257 4030016790 S.CER ECJ0EB1C103K B 19.9/37.8
C260 4030018910 S.CER C1608 JB 0J 475K-T B 24/6.6
C261 4030016930 S.CER ECJ0EB1A104K B 35.3/25.6
C262 4030016790 S.CER ECJ0EB1C103K B 36.3/36
C263 4030016790 S.CER ECJ0EB1C103K B 17.7/23.5
C264 4030017770 S.CER ECJ0EB1E332K B 32.3/37.9
C265 4030017420 S.CER ECJ0EC1H470J B 29.4/33.9
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C266 4030016950 S.CER ECJ0EB1A473K B 30.3/37.7
C267 4030018860 S.CER ECJ0EB0J105K B 30/36.5
C280 4030018860 S.CER ECJ0EB0J105K B 16.1/28.4
C282 4550007080 S.TAN TEESVA 1C 106M8R B 11.9/11.6
C283 4030016930 S.CER ECJ0EB1A104K B 15/16.7
C284 4030017460 S.CER ECJ0EB1E102K B 15/17.6
C285 4030016930 S.CER ECJ0EB1A104K B 19.2/29.5
C286 4550006250 S.TAN TEESVA 1A 106M8R B 19.9/12.3
C287 4030017700 S.CER ECJ0EC1H151J B 15.5/8.1
C288 4030016950 S.CER ECJ0EB1A473K B 10.3/9.3
C289 4510009010 S.ELE EEE1AA221P B 68.6/29.9
C300 4030017770 S.CER ECJ0EB1E332K B 23.9/24.6
C340 4030016790 S.CER ECJ0EB1C103K B 71.8/34.6
C341 4030017030 S.CER ECJ0EB1A273K B 69.9/39
C350 4030017460 S.CER ECJ0EB1E102K B 53.5/2
C351 4030017420 S.CER ECJ0EC1H470J B 77.4/35
C352 4030017420 S.CER ECJ0EC1H470J B 78.7/34.1
C376 4030016930 S.CER ECJ0EB1A104K B 18.7/40.8
C377 4030017740 S.CER ECJ0EB1E821K B 23.6/28.9
C378 4030017780 S.CER ECJ0EB1E472K B 20.8/30.7
C379 4030017500 S.CER ECJ0EC1H560J B 20/32.2
C401 4030018870 S.CER ECJ0EF0J105Z B 17.3/16.8
C402 4030018870 S.CER ECJ0EF0J105Z B 17.7/31.8
C403 4550006250 S.TAN TEESVA 1A 106M8R B 25/19.8
C404 4030016790 S.CER ECJ0EB1C103K B 23/23.4
C405 4030016930 S.CER ECJ0EB1A104K B 15.2/20.4
C410 4030018860 S.CER ECJ0EB0J105K [scramble] only B 49.6/8
C411 4030018860 S.CER ECJ0EB0J105K [scramble] only B 49.6/11.2
C412 4030018860 S.CER ECJ0EB0J105K [scramble] only B 51.3/15.3
C413 4030016930 S.CER ECJ0EB1A104K [scramble] only B 32/21.8
C414 4030016930 S.CER ECJ0EB1A104K [scramble] only B 36/23
C415 4030018860 S.CER ECJ0EB0J105K [scramble] only B 36.8/16.8
C416 4030018860 S.CER ECJ0EB0J105K [scramble] only B 36.8/18.4
C417 4030016790 S.CER ECJ0EB1C103K [scramble] only B 36.8/21.6
C418 4030016790 S.CER ECJ0EB1C103K [scramble] only B 31.1/18.6
C419 4030016930 S.CER ECJ0EB1A104K [scramble] only B 55.6/16.3
C420 4030017650 S.CER ECJ0EC1H270J [scramble] only B 67.1/4.3
C421 4030017650 S.CER ECJ0EC1H270J [scramble] only B 62.2/4.2
C422 4030017690 S.CER ECJ0EC1H121J [scramble] only B 62.3/11.6
C423 4030016930 S.CER ECJ0EB1A104K [scramble] only B 64.9/5.1
C424 4030018860 S.CER ECJ0EB0J105K [scramble] only B 49.6/9.6
C425 4030018860 S.CER ECJ0EB0J105K [scramble] only B 49.8/4.8
C430 4030018860 S.CER ECJ0EB0J105K B 12.5/35.1
C431 4030018860 S.CER ECJ0EB0J105K B 14.8/40.8
C432 4030016930 S.CER ECJ0EB1A104K B 8.9/34
C433 4030017460 S.CER ECJ0EB1E102K B 12/31.8
C434 4030016960 S.CER ECJ0EB1C183K B 12.8/6.8
C435 4030016960 S.CER ECJ0EB1C183K B 10.5/7.5
C436 4030017730 S.CER ECJ0EB1E471K B 10.5/6.5
C437 4030017460 S.CER ECJ0EB1E102K B 7.7/6.6
C438 4030016930 S.CER ECJ0EB1A104K B 14.8/6.8
C439 4030016930 S.CER ECJ0EB1A104K B 6.7/4.3
C450 4030018860 S.CER ECJ0EB0J105K B 28/27.5
C451 4030018860 S.CER ECJ0EB0J105K Except [AUS] only B 29.3/27
C482 4030017400 S.CER ECJ0EC1H220J B 85.9/25.8
C483 4030017400 S.CER ECJ0EC1H220J B 85/24.2
C488 4550006250 S.TAN TEESVA 1A 106M8R B 65/21.6
C489 4030016790 S.CER ECJ0EB1C103K B 66.6/21.8
C490 4030016790 S.CER ECJ0EB1C103K B 66.5/24.4
C491 4030016950 S.CER ECJ0EB1A473K B 85.3/22.9
C492 4030017460 S.CER ECJ0EB1E102K B 85.6/21.1
C493 4030016950 S.CER ECJ0EB1A473K B 85.5/19
C494 4030016950 S.CER ECJ0EB1A473K B 85.6/15.1
C495 4030017040 S.CER ECJ0EB1A333K B 85.9/16.9
C496 4030016950 S.CER ECJ0EB1A473K B 85.5/18.1
C497 4030016950 S.CER ECJ0EB1A473K B 85.2/7.9
C498 4030016950 S.CER ECJ0EB1A473K B 85.2/6.2
C499 4030016950 S.CER ECJ0EB1A473K B 84.3/6
C500 4030016930 S.CER ECJ0EB1A104K B 83.4/6.4
C502 4030018900 S.CER ECJ0EB0J474K B 81.7/8.2
C503 4030018900 S.CER ECJ0EB0J474K B 78.5/4.7
C504 4030018900 S.CER ECJ0EB0J474K B 77.6/4.7
C505 4030018900 S.CER ECJ0EB0J474K B 82.3/9.4
J100 6510025130 S.CNR 30P9.0-JMCS-G-B-TF (N) B 61.3/20.3
J251 6510021900 S.CNR BM02B-ASRS-TF T 6.6/3
J260 6510022690 S.CNR 06FLT-SM1-TB Except [AUS] only B 65.3/40.1
J300 6510025140 S.CNR 10FLT-SM1-TB B 76.6/29.7
DS240 5040003010 S.LED SML-A12WT T 63.5/2.1
DS241 5040003010 S.LED SML-A12WT T 73.5/2.1
DS242 5040002310 S.LED SML-311YTT86 T 38.9/12.3
DS243 5040002310 S.LED SML-311YTT86 T 38.9/30.3
DS250 5040003010 S.LED SML-A12WT T 63.5/40.4
DS251 5040003010 S.LED SML-A12WT T 73.5/40.4
DS252 5040002310 S.LED SML-311YTT86 T 23.6/11.8
DS253 5040002310 S.LED SML-311YTT86 T 23.6/30.8
DS480 5030002910 LCD L5-0213TVM
[scramble]=[USA-1], [SEA-1], [AUS-1]
