Icom IC-M72

6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC170 1110003201 S.IC TA31136FNG (EL) B 52/32.6
IC200 1110003780 S.IC NJM2902V-TE1 B 25.1/32.2
IC220 1110005350 S.IC NJM2870F05-TE1 B 22.8/12.3
IC260 1130011770 S.IC CD4066BPWR B 32.7/30.8
IC280 1110001810 S.IC TA7368F (ER) [USA], [SEA] B 15.9/12.4
1110001811 S.IC TA7368FG (5 ER)
[AUS], [scramble] B 15.9/12.4
IC340 1130012430 S.IC S-24CS64A0I-T8T1G B 67.3/36.2
IC341 1110005770 S.IC S-80942CNMC-G9C-T2 [AUS] B 72.4/39.2
1110005771 S.IC S-80942CNMC-G9CT2G
Except [AUS] B 72.4/39.2
IC360 1140010620 S.IC µPD78F0338GC-9EB [AUS] B 74.2/14.6
1140013300 S.IC µPD78F0338GC-9EB-A
Except [AUS] B 74.2/14.6
IC401 1110002420 S.IC NJM2073M-TE1 B 19.7/20.2
IC410 1130009900 S.IC FX214L2/TR [scramble] only B 56/9.5
IC411 1110006380 S.IC LM2904PWR [scramble] only B 34.4/18.7
IC412 1130007991 S.IC TC3W03FU (TE12L F)
[scramble] only B 63.5/8.2
IC430 1130011770 S.IC CD4066BPWR B 16.7/36.5
IC431 1110006380 S.IC LM2904PWR B 12/3.1
Q221 1510001090 S.TR KTA2015Y-RTK/P B 28.4/19.4
Q223 1590003290 S.TR UNR9213J-(TX) B 25.7/11.6
Q224 1590001190 S.TR XP6501-(TX) AB B 25.7/16
Q225 1520000840 S.TR KTA1664Y-RTF/P B 28.6/13.6
Q230 1550000090 S.FET RSQ035P03TR B 29.4/9.2
Q231 1590001190 S.TR XP6501-(TX) AB B 33/8.2
Q240 1590003290 S.TR UNR9213J-(TX) B 84.7/35.9
Q250 1590003380 S.TR UNR9111J-(TX) B 10.2/37.1
Q350 1590003270 S.TR UNR9210J-(TX) B 78.9/37.8
Q351 1590003550 S.TR XP4313 (TX) B 75.5/39.9
Q400 1590003290 S.TR UNR9213J-(TX) B 13.3/33.2
Q401 1590003290 S.TR UNR9213J-(TX) B 34.2/5.4
Q430 1590003380 S.TR UNR9111J-(TX) B 10.1/35
Q450 1590001770 S.TR XP1213 (TX) B 25.6/23.9
Q451 1590003290 S.TR UNR9213J-(TX) B 27.9/23.9
Q470 1590003290 S.TR UNR9213J-(TX) B 14.2/25.4
Q500 1590003290 S.TR UNR9213J-(TX) B 80.1/4.6
Q540 1590003230 S.TR UNR9113J-(TX) B 35.3/7.7
Q541 1590003290 S.TR UNR9213J-(TX) [scramble] only B 66.8/1.3
D350 1750001180 S.DIO KDS122 RTK/P B 81.3/37.8
D430 1790001250 S.DIO MA2S111-(TX) B 9.1/6.1
FI170 2020001530 CER CFWLB450KFFA-B0 [AUS] B 59/32.9
2020002170 S.CER ELFY450E Except [AUS] B 59/32.9
X170 6070000190 S.DCR CDBCB450KCAY24-R0 B 54.1/21.5
X410 6050008910 XTL AT-38 (4.000 MHz) [scramble] only
X480 6050011500 S.XTL CR-739 (9.8304 MHz) B 81.9/29.2
R170 7030009280 S.RES ERJ2GEJ 391 X (390) B 50.3/24.6
R171 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
)
B 50.3/26.2
R172 7030005000 S.RES ERJ2GEJ 471 X (470) B 54/27.1
R173 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 50.7/36.9
R174 7030006610 S.RES ERJ2GEJ 394 X (390 k
)
B 53.8/36.9
R175 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
B 54/38.1
R176 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 52.2/38.9
R201 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 28/29.1
R202 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 29.2/29.1
R203 7030003810 S.RES ERJ3GEYJ 125 V (1.2 M
)
B 26.5/27.5
R204 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 25.2/28.9
R205 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
)
B 22.9/24.6
R206 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
B 22.4/26.9
R207 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
B 24.7/27.9
R212 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 21.5/28.3
R213 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 21.1/27
R214 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 19.8/27.7
R222 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 26.8/17.8
R223 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 28.4/17.6
R226 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 25/13.4
R227 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 31.7/13.1
R228 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 23.8/16
R230 7030005600 S.RES ERJ2GEJ 273 X (27 k
)
B 30.7/6.2
R231 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
B 32.7/5.9
R232 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 32.7/11.4
R233 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 33.1/10.1
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R234 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
B 34.8/9.7
R235 7030005930 S.RES ERJ3GEYF 334 V (330 k
)
B 32.8/13.5
R236 7030008090 S.RES ERJ3EKF 1503 V (150 k
)
B 31.8/16
R240 7030007280 S.RES ERJ2GEJ 331 X (330) [AUS] B 65.4/4.2
7030008280 S.RES ERJ2GEJ 271 X (270)
Except [AUS] B 65.4/4.2
R241 7030005010 S.RES ERJ2GEJ 681 X (680) T 38.9/21.3
R243 7030007280 S.RES ERJ2GEJ 331 X (330) [AUS] B 52.8/40.9
7030008280 S.RES ERJ2GEJ 271 X (270)
Except [AUS] B 52.8/40.9
R244 7030005010 S.RES ERJ2GEJ 681 X (680) T 23.6/21.3
R245 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 17.7/7
R250 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
[AUS] B 7.6/35.2
7030005700 S.RES ERJ2GEJ 274 X (270 k
)
Except [AUS] B 7.6/35.2
R251 7030005000 S.RES ERJ2GEJ 471 X (470) B 12.1/36.3
R252 7030005060 S.RES ERJ2GEJ 333 X (33 k
)
B 9.5/39.6
R253 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 21/35.9
R255 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 21.9/35.2
R256 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
B 20/36.2
R257 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 22.3/36.4
R258 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 24.7/35.5
R259 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
B 23.1/35.5
R260 7030005671 S.RES ERA3YKD 393V (39 k
)
B 20.3/7.5
R261 7030009591 S.RES ERA3YED 472V (4.7 k
)
B 18.9/7.5
R262 7030006601 S.RES ERA3YED 272V (2.7 k
)
B 22.1/6.1
R263 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 35.7/27.6
R264 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 30.7/26.5
R265 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 35.3/36
R271 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
B 33.2/36.6
R272 7030005700 S.RES ERJ2GEJ 274 X (270 k
)
B 31.8/36.5
R273 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 31.8/35.6
R274 7030006610 S.RES ERJ2GEJ 394 X (390 k
)
B 19/24.3
R275 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 20.3/24
R276 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 17.7/24.4
R277 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 29.4/32.3
R278 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 31.2/37.7
R279 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 28.5/35.1
R283 7030007260 S.RES ERJ2GEJ 330 X (33) B 19.3/9.3
R284 7030005530 S.RES ERJ2GEJ 100 X (10) B 12.3/8.6
R286 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 17.8/28.6
R288 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 18.8/25.5
R289 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 17.5/26.3
R290 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 16.2/25.9
R300 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
)
B 24/25.9
R340 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 72/35.9
R341 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 72/36.8
R343 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 73.2/36.6
R350 7030005170 S.RES ERJ2GEJ 474 X (470 k
)
B 52.3/2.5
R351 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 77.8/36.2
R352 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
B 78.6/35.3
R353 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 77.4/37.4
R354 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 76.2/37.3
R355 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 76.2/35.9
R356 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 77.4/39
R357 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 75/38.2
R358 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
Except [AUS] B 61.8/39.5
7030010040 S.RES ERJ2GEJ-JPW [AUS] B 61.8/39.5
R359 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 79.7/36.2
R375 7030005290 S.RES ERJ2GEJ 682 X (6.8 k
)
B 20/39.7
R376 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 24/26.9
R377 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 23.1/27.9
R378 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 21.3/29.3
R379 7030005080 S.RES ERJ2GEJ 823 X (82 k
)
B 19.9/30.8
R393 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 32.6/26
R394 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 34.1/36
R395 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
[scramble] only B 34.7/26.5
R400 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 15.2/31.3
R401 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 16.1/24.1
R402 7030005530 S.RES ERJ2GEJ 100 X (10) B 15.2/18.8
R403 7030005170 S.RES ERJ2GEJ 474 X (470 k
)
B 16.4/31.8
R410 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
[scramble] only B 32.7/23
R411 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
[scramble] only B 34.3/23
R412 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
[scramble] only B 32/20.2
R413 7030008290 S.RES ERJ2GEJ 183 X (18 k
)
[scramble] only B 34.6/13.5
R414 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
[scramble] only B 34.6/14.4
[scramble]=[USA-1], [SEA-1], [AUS-1]
