6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R81 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
T 22/17.2
R82 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 21.7/16
R85 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
Except [AUS] T 32.5/13.2
7030005220 S.RES ERJ2GEJ 223 X (22 k
)
[AUS] T 32.5/13.2
R90 7030005590 S.RES ERJ2GEJ 680 X (68) B 32.7/10.5
R91 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 29.9/17.6
R93 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 28.8/19.4
R94 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 27.5/18.1
R95 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
Except [AUS] B 22.3/18.6
7030008290 S.RES ERJ2GEJ 183 X (18 k
)
[AUS] B 22.3/18.6
R96 7030005100 S.RES ERJ2GEJ 154 X (150 k
)
[AUS] B 20.5/16.6
7030005700 S.RES ERJ2GEJ 274 X (270 k
)
Except [AUS] B 20.5/16.6
R97 7030005000 S.RES ERJ2GEJ 471 X (470) B 20.8/18.5
R98 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 22.8/19.8
R99 7030005170 S.RES ERJ2GEJ 474 X (470 k
)
B 23.7/16.7
R100 7030010040 S.RES ERJ2GEJ-JPW T 4.9/9.8
R101 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
)
B 22.5/13.6
R102 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 20.5/14
R103 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 21.7/17.3
R104 7030009270 S.RES ERJ2GEJ 821 X (820) B 16.2/15.3
R105 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 16.2/20.3
R106 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 16.5/21.5
R107 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 15.3/20.3
R108 7030010040 S.RES ERJ2GEJ-JPW B 12/19.3
R109 7030005530 S.RES ERJ2GEJ 100 X (10) B 9.2/21.6
R110 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
)
B 7.2/15.5
R111 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 11.7/15.6
R115 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 8.9/15.4
R120 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 8.2/20.2
R121 7030007350 S.RES ERJ2GEJ 393 X (39 k
)
B 9.3/14.2
R122 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
B 10.2/14.2
R152 7030004980 S.RES ERJ2GEJ 101 X (100) B 2.7/12.2
R153 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 2.3/28.4
R154 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 5.6/29
R155 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 6.9/25.2
R156 7030005000 S.RES ERJ2GEJ 471 X (470) B 7.5/26.4
R192 7030009280 S.RES ERJ2GEJ 391 X (390
)
T 23.4/32.6
R193 7030005000 S.RES ERJ2GEJ 471 X (470) T 20/28.8
R194 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
T 25.4/29.6
R220 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 20.1/24.3
R221 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 19.2/23.5
R224 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 27/17.6
R225 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
T 24.9/17.5
R230 7030005070 S.RES ERJ2GEJ 683 X (68 k
)
B 29.4/24.8
R380 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
T 22.6/10.5
R381 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 25.5/21.8
R382 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
)
B 26.3/19.3
R383 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
B 25.5/20.2
R384 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 25.1/24.5
R386 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 25.9/31.3
R510 7030005700 S.RES ERJ2GEJ 274 X (270 k
)
B 3.9/6.4
R511 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 3.5/7.7
C1 4030016930 S.CER ECJ0EB1A104K B 6/30.6
C2 4030016790 S.CER ECJ0EB1C103K B 3.7/33.1
C3 4030017440 S.CER ECJ0EC1H221J B 3.3/38.1
C4 4030017390 S.CER ECJ0EC1H180J B 3.3/39.4
C5 4030017640 S.CER ECJ0EC1H150J B 9/39.7
C6 4030017460 S.CER ECJ0EB1E102K T 19.1/30
C7 4030016790 S.CER ECJ0EB1C103K T 4.2/29.4
C8 4030017350 S.CER ECJ0EC1H020B T 3.9/34
C9 4030017350 S.CER ECJ0EC1H020B T 4.2/35.2
C10 4030016950 S.CER ECJ0EB1A473K T 13.4/34.1
C11 4550000270 S.TAN TEESVA 1E 474M8R
Except [AUS] T 15.5/36.2
4550002980 S.TAN TEESVA 1C 225M8R [others] T 15.5/36.2
C12 4030017460 S.CER ECJ0EB1E102K T 3.4/32.4
C15 4030017460 S.CER ECJ0EB1E102K T 25.3/35.4
C16 4030017460 S.CER ECJ0EB1E102K T 21.4/37.7
C17 4030017460 S.CER ECJ0EB1E102K T 25.2/33.5
C20 4030017460 S.CER ECJ0EB1E102K B 13.7/36.6
C21 4030017610 S.CER ECJ0EC1H090C B 12.8/36.6
C22 4030017610 S.CER ECJ0EC1H090C B 10.3/36.8
C24 4030016930 S.CER ECJ0EB1A104K B 22.9/36.6
C25 4030017460 S.CER ECJ0EB1E102K B 22.9/35
C26 4030007080 S.CER C1608 CH 1H 390J-T B 21/33.3
C27 4030007080 S.CER C1608 CH 1H 390J-T B 19.3/36
C28 4030017460 S.CER ECJ0EB1E102K B 17.2/36
C29 4030017460 S.CER ECJ0EB1E102K B 18.1/35.5
C30 4030017460 S.CER ECJ0EB1E102K B 16/36.5
C31 4030017460 S.CER ECJ0EB1E102K B 16.8/25.6
C32 4030017550 S.CER ECJ0EC1H1R5B B 17.7/30.1
C33 4030017440 S.CER ECJ0EC1H221J B 19.2/28.5
C34 4030017550 S.CER ECJ0EC1H1R5B B 20.2/28.5
C35 4030017460 S.CER ECJ0EB1E102K B 18.5/24.6
C36 4030017460 S.CER ECJ0EB1E102K B 14.7/30.3
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C37 4030017530 S.CER ECJ0EC1H0R5B B 16.1/29.1
C38 4030017460 S.CER ECJ0EB1E102K B 10.8/27.1
C39 4030017630 S.CER ECJ0EC1H120J B 10.8/29.2
C40 4030017640 S.CER ECJ0EC1H150J B 13.1/26.9
C41 4030017460 S.CER ECJ0EB1E102K B 10.8/31.1
C42 4030017380 S.CER ECJ0EC1H050B B 10.8/30.1
C43 4030017400 S.CER ECJ0EC1H220J B 10.7/35.6
C44 4030017460 S.CER ECJ0EB1E102K T 16.2/30.8
C50 4030017460 S.CER ECJ0EB1E102K T 6.3/11.7
C51 4030017400 S.CER ECJ0EC1H220J T 5.1/8.2
C52 4030017460 S.CER ECJ0EB1E102K T 4.2/7
C53 4030017460 S.CER ECJ0EB1E102K T 2.4/2.8
C54 4030017640 S.CER ECJ0EC1H150J T 8.6/3
C55 4030017410 S.CER ECJ0EC1H240J T 9.8/3.1
C56 4030016790 S.CER ECJ0EB1C103K B 29.4/26.4
C57 4030016930 S.CER ECJ0EB1A104K B 25.4/29.5
C58 4030016930 S.CER ECJ0EB1A104K B 25.3/23
C59 4030017730 S.CER ECJ0EB1E471K B 28.3/22.7
C60 4030017460 S.CER ECJ0EB1E102K B 26.7/20.7
C61 4510008490 S.ELE EEE1CS100SR T 18.6/16
C62 4030017460 S.CER ECJ0EB1E102K T 16.7/13.7
C63 4030017730 S.CER ECJ0EB1E471K T 13.9/13.6
C64 4030017460 S.CER ECJ0EB1E102K T 12.2/3.3
C65 4030017430 S.CER ECJ0EC1H101J T 12.4/5
C66 4030017460 S.CER ECJ0EB1E102K T 14.3/2.5
C67 4030017730 S.CER ECJ0EB1E471K T 18.8/12.1
C68 4030017420 S.CER ECJ0EC1H470J T 22.2/13
C70 4030007100 S.CER C1608 CH 1H 560J-T T 21.9/1.7
C71 4030009650 S.CER C1608 CH 1H 240J-T T 25.9/3.7
C72 4030006860 S.CER C1608 JB 1H 102K-T T 23.3/5.1
C73 4030017460 S.CER ECJ0EB1E102K T 29.8/11.5
C74 4030017460 S.CER ECJ0EB1E102K T 26.7/8.5
C80 4030017460 S.CER ECJ0EB1E102K T 28.5/4.7
C81 4030017400 S.CER ECJ0EC1H220J T 24.9/5
C82 4030017400 S.CER ECJ0EC1H220J T 25.1/5.9
C83 4030017400 S.CER ECJ0EC1H220J T 28.2/3.8
C84 4030018120 S.CER ECJ0EC1H110J T 30.2/4.2
C85 4030017640 S.CER ECJ0EC1H150J T 29.8/5.5
C86 4030017610 S.CER ECJ0EC1H090C T 30.5/9.3
C87 4030017530 S.CER ECJ0EC1H0R5B B 24.1/4.5
C88 4030017460 S.CER ECJ0EB1E102K T 23.7/17.1
C89 4030017590 S.CER ECJ0EC1H070C T 32.3/4.2
C90 4030007000 S.CER C1608 CH 1H 090D-T B 23.5/2.8
C91 4030017620 S.CER ECJ0EC1H100C B 26.7/6.2
C92 4030017360 S.CER ECJ0EC1H030B B 27.6/9
C93 4030017460 S.CER ECJ0EB1E102K B 31.1/10.5
C94 4030017370 S.CER ECJ0EC1H3R5B B 26/9.2
C95 4030017650 S.CER ECJ0EC1H270J B 29.5/15
C96 4030017460 S.CER ECJ0EB1E102K B 23/21.4
C97 4030017360 S.CER ECJ0EC1H030B B 26/10.8
C98 4030017550 S.CER ECJ0EC1H1R5B B 27.2/10.2
C99 4030017500 S.CER ECJ0EC1H560J B 28.1/16.6
C100 4030017560 S.CER ECJ0EC1H2R5B B 27.4/11.4
C101 4030017610 S.CER ECJ0EC1H090C B 23.8/18
C102 4030016790 S.CER ECJ0EB1C103K B 19.6/18
C103 4030017420 S.CER ECJ0EC1H470J B 19.6/18.9
C104 4030016790 S.CER ECJ0EB1C103K B 19.7/20.1
C106 4030018900 S.CER ECJ0EB0J474K B 22.6/17.3
C107 4030017460 S.CER ECJ0EB1E102K B 19.6/14
C108 4030017420 S.CER ECJ0EC1H470J B 18.7/14
C109 4030017460 S.CER ECJ0EB1E102K B 16.9/16.8
C110 4030017680 S.CER ECJ0EC1H820J B 15.9/19.1
C111 4030017460 S.CER ECJ0EB1E102K B 14.9/21.5
C112 4030017370 S.CER ECJ0EC1H3R5B B 16.2/14.3
C113 4030017540 S.CER ECJ0EC1HR75B B 14.6/16
C114 4030017660 S.CER ECJ0EC1H330J B 14.1/20.6
C115 4030017380 S.CER ECJ0EC1H050B B 14/17.2
C116 4030017570 S.CER ECJ0EC1H040B B 13/16
C119 4030017500 S.CER ECJ0EC1H560J B 7.3/17.9
C120 4030016970 S.CER ECJ0EB1C223K B 8.2/17.5
C121 4030017460 S.CER ECJ0EB1E102K B 7.2/16.4
C122 4030017460 S.CER ECJ0EB1E102K T 7.6/18.6
C123 4030017460 S.CER ECJ0EB1E102K T 7.9/13.3
C130 4030017640 S.CER ECJ0EC1H150J T 8.2/17.1
C131 4030017620 S.CER ECJ0EC1H100C T 7.9/12.4
C132 4030017550 S.CER ECJ0EC1H1R5B B 6.8/14.3
C154 4030017460 S.CER ECJ0EB1E102K B 4.7/11.7
C155 4030017580 S.CER ECJ0EC1H060C T 3.7/20.8
C156 4030017460 S.CER ECJ0EB1E102K B 2.6/29.6
C157 4030016970 S.CER ECJ0EB1C223K B 4.7/29.2
C158 4030017460 S.CER ECJ0EB1E102K B 3.8/29.2
C159 4030016790 S.CER ECJ0EB1C103K B 7.9/25.2
C160 4030016790 S.CER ECJ0EB1C103K B 10.1/21.6
C191 4030016790 S.CER ECJ0EB1C103K T 19.7/27.7
C192 4550006050 S.TAN TEESVA 0J 106M8R T 21.6/32.5
C193 4030016790 S.CER ECJ0EB1C103K T 21.6/29.1
C194 4030016790 S.CER ECJ0EB1C103K T 20/30
C220 4550006250 S.TAN TEESVA 1A 106M8R T 14.3/26.9
C221 4030016790 S.CER ECJ0EB1C103K T 18.1/23.5
C223 4030016790 S.CER ECJ0EB1C103K T 26.1/17.3
[scramble]=[USA-1], [SEA-1], [AUS-1]
