[2NDCVCO BOARD][1STBVCO BOARD]
C30 4030017460 S.CERAMIC ECJ0EB1E102K T
C31 4030017460 S.CERAMIC ECJ0EB1E102K B
C35 4030017770 S.CERAMIC ECJ0EB1E332K B
C37 4550003220 S.TANTALUM TEESVA 1E 105M8L B
C38 4550000930 S.TANTALUM TEESVA 1D 684M8L B
C39 4550000930 S.TANTALUM TEESVA 1D 684M8L B
C40 4030016790 S.CERAMIC ECJ0EB1C103K B
C41 4030017460 S.CERAMIC ECJ0EB1E102K B
C42 4030017460 S.CERAMIC ECJ0EB1E102K B
C43 4030017350 S.CERAMIC ECJ0EC1H020B B
C44 4030017460 S.CERAMIC ECJ0EB1E102K B
C45 4030017530 S.CERAMIC ECJ0EC1H0R5B T
C46 4030017460 S.CERAMIC ECJ0EB1E102K B
C47 4030017460 S.CERAMIC ECJ0EB1E102K B
C48 4340000290 S.MYLAR ECHU 1C 103JX5 B
C49 4030017620 S.CERAMIC ECJ0EC1H100C B
C50 4030017380 S.CERAMIC ECJ0EC1H050B B
C52 4030017460 S.CERAMIC ECJ0EB1E102K B
C53 4030017460 S.CERAMIC ECJ0EB1E102K B
C54 4030017460 S.CERAMIC ECJ0EB1E102K T
C55 4030017460 S.CERAMIC ECJ0EB1E102K T
C56 4030017460 S.CERAMIC ECJ0EB1E102K T
C57 4030017460 S.CERAMIC ECJ0EB1E102K T
C58 4030016930 S.CERAMIC ECJ0EB1A104K B
C59 4030016790 S.CERAMIC ECJ0EB1C103K B
C60 4030016790 S.CERAMIC ECJ0EB1C103K B
C61 4030016930 S.CERAMIC ECJ0EB1A104K B
C62 4030016930 S.CERAMIC ECJ0EB1A104K B
C63 4030017460 S.CERAMIC ECJ0EB1E102K B
C64 4550007040 S.TANTALUM ECST0JZ106R B
C65 4550007040 S.TANTALUM ECST0JZ106R B
C66 4550007040 S.TANTALUM ECST0JZ106R B
C67 4550007040 S.TANTALUM ECST0JZ106R B
C68 4030017460 S.CERAMIC ECJ0EB1E102K
[EUR], [UK], [USA], [CAN] only B
J1 6910015520 CONNECTOR IMSA-9230B-1-07Z064-T B
J2 6910015510 CONNECTOR IMSA-9230B-1-08Z064-T B
EP1 0910058174 PCB B 6081D
IC1 1130011670 S.IC MB15E03SLPFV1-G-BND-ER B
Q1 1530003610 S.TRANSISTOR FH102-TL T
Q3 1530003590 S.TRANSISTOR 2SC5277D2-TL T
Q4 1530003630 S.TRANSISTOR 2SC4617 TLS T
D1 1750000740 S.VARICAP 1SV314 (TPH3) T
L1 6200009070 S.COIL
LQW18AN18NG00D (LQW1608A18NG00)
T
L2 6200005720 S.COIL ELJRE 33NG-F T
L3 6200005700 S.COIL ELJRE 22NG-F T
L4 6200009350 S.COIL ELJRE R22G-F3 T
R1 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) T
R2 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R3 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R4 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R9 7030005580 S.RESISTOR ERJ2GEJ 560 X (56 Ω) B
R10 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R11 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R12 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R13 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R14 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R15 7030009270 S.RESISTOR ERJ2GEJ 821 X (820 Ω) B
R16 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
S.=Surface mount
R17 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ) T
R18 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R19 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R21 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R22 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω) B
C1 4550006910 S.TANTALUM TEESVP 1C 334M8R T
C2 4030017390 S.CERAMIC ECJ0EC1H180J T
C3 4030017640 S.CERAMIC ECJ0EC1H150J T
C4 4030017620 S.CERAMIC ECJ0EC1H100C T
C5 4030017630 S.CERAMIC ECJ0EC1H120J T
C6 4030017460 S.CERAMIC ECJ0EB1E102K T
C7 4030017570 S.CERAMIC ECJ0EC1H040B T
C8 4030017340 S.CERAMIC ECJ0EC1H010B T
C9 4030017380 S.CERAMIC ECJ0EC1H050B T
C10 4030017380 S.CERAMIC ECJ0EC1H050B T
C16 4030017730 S.CERAMIC ECJ0EB1E471K B
C17 4030017380 S.CERAMIC ECJ0EC1H050B B
C18 4030017420 S.CERAMIC ECJ0EC1H470J B
C19 4030017420 S.CERAMIC ECJ0EC1H470J B
C20 4030017420 S.CERAMIC ECJ0EC1H470J B
C21 4550007150 S.TANTALUM ECST0JZ475R B
C22 4030016790 S.CERAMIC ECJ0EB1C103K T
C23 4030016790 S.CERAMIC ECJ0EB1C103K T
C24 4030016790 S.CERAMIC ECJ0EB1C103K T
C25 4030017460 S.CERAMIC ECJ0EB1E102K B
C26 4030016930 S.CERAMIC ECJ0EB1A104K B
C27 4030017460 S.CERAMIC ECJ0EB1E102K B
C30 4030017460 S.CERAMIC ECJ0EB1E102K T
C31 4030017460 S.CERAMIC ECJ0EB1E102K T
C32 4550007040 S.TANTALUM ECST0JZ106R T
C33 4030017350 S.CERAMIC ECJ0EC1H020B T
J1 6910010840 CONNECTOR IMSA-9230B-1-05Z057-T T
J2 6910014430 CONNECTOR IMSA-9230B-1-06Z057-T T
EP1 0910058183 PCB B 6082C
IC1 1130011670 S.IC MB15E03SLPFV1-G-BND-ER B
Q1 1530003610 S.TRANSISTOR FH102-TL T
Q3 1530003590 S.TRANSISTOR 2SC5277D2-TL T
Q4 1530003630 S.TRANSISTOR 2SC4617 TLS T
D1 1750000710 S.VARICAP HVC350BTRF T
L1 6200010850 S.COIL
LQW18AN22NG00D (LQW1608A22NG00)
T
L2 6200005740 S.COIL ELJRE 47NG-F T
L3 6200005700 S.COIL ELJRE 22NG-F T
L4 6200009350 S.COIL ELJRE R22G-F3 T
R1 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) T
R2 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ) T
R3 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω) T
R4 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R9 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) B
R10 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω) B
R11 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R12 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R13 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R14 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R15 7030009270 S.RESISTOR ERJ2GEJ 821 X (820 Ω) B
R16 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R17 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ) T
R18 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
6 - 3
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
NO. NO.
[2NDCVCO BOARD]
REF ORDER
DESCRIPTION M.
NO. NO.
[2NDDVCO BOARD]
To Next Page
