Icom IC-R20

[DOWNCONV BOARD][2NDDVCO BOARD]
R19 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R21 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R22 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω) B
C1 4550006910 S.TANTALUM TEESVP 1C 334M8R T
C2 4030017500 S.CERAMIC ECJ0EC1H560J T
C3 4030017400 S.CERAMIC ECJ0EC1H220J T
C4 4030017630 S.CERAMIC ECJ0EC1H120J T
C5 4030017650 S.CERAMIC ECJ0EC1H270J T
C6 4030017460 S.CERAMIC ECJ0EB1E102K T
C7 4030017620 S.CERAMIC ECJ0EC1H100C T
C8 4030017570 S.CERAMIC ECJ0EC1H040B T
C9 4030017600 S.CERAMIC ECJ0EC1H080C T
C10 4030017600 S.CERAMIC ECJ0EC1H080C T
C16 4030017730 S.CERAMIC ECJ0EB1E471K B
C17 4030017380 S.CERAMIC ECJ0EC1H050B B
C18 4030017420 S.CERAMIC ECJ0EC1H470J B
C19 4030017420 S.CERAMIC ECJ0EC1H470J B
C20 4030017420 S.CERAMIC ECJ0EC1H470J B
C21 4550007150 S.TANTALUM ECST0JZ475R B
C22 4030016790 S.CERAMIC ECJ0EB1C103K T
C23 4030016790 S.CERAMIC ECJ0EB1C103K T
C24 4030016790 S.CERAMIC ECJ0EB1C103K T
C25 4030017460 S.CERAMIC ECJ0EB1E102K B
C26 4030016930 S.CERAMIC ECJ0EB1A104K B
C27 4030017460 S.CERAMIC ECJ0EB1E102K B
C30 4030017460 S.CERAMIC ECJ0EB1E102K T
C31 4030017460 S.CERAMIC ECJ0EB1E102K T
C32 4550007040 S.TANTALUM ECST0JZ106R T
J1 6910010840 CONNECTOR IMSA-9230B-1-05Z057-T T
J2 6910014430 CONNECTOR IMSA-9230B-1-06Z057-T T
EP1 0910058193 PCB B 6083C
IC2 1110005120 S.IC µPC2749TB-E3 T
IC3 1110005230 S.IC µPC2757TB-E3 T
IC4 1130011670 S.IC MB15E03SLPFV1-G-BND-ER B
Q1 1530003260 S.TRANSISTOR 2SC5006-T1 T
Q2 1530003260 S.TRANSISTOR 2SC5006-T1 B
Q3 1590003380 S.TRANSISTOR UNR9111J-(TX) B
Q4 1530003780 S.TRANSISTOR 2SC5624VH-TL T
Q5 1590001810 S.TRANSISTOR XP1113 (TX) B
Q6 1530003590 S.TRANSISTOR 2SC5277D2-TL B
D1 1790001620 S.DIODE 1SV308 (TPL3) T
D2 1790001620 S.DIODE 1SV308 (TPL3) B
D3 1720000400 S.VARICAP 1SV245 (TPH3) T
D5 1790001620 S.DIODE 1SV308 (TPL3) T
D6 1790001620 S.DIODE 1SV308 (TPL3) T
D7 1790001620 S.DIODE 1SV308 (TPL3) T
D8 1790001620 S.DIODE 1SV308 (TPL3) T
L1 6200005650 S.COIL ELJRE 8N2Z-F T
L2 6200005650 S.COIL ELJRE 8N2Z-F T
L3 6200004480 S.COIL MLF1608D R82K-T T
L4 6200010020 S.COIL C2012C-12NG T
L6 6200009350 S.COIL ELJRE R22G-F3 T
L7 6200006770 S.COIL ELJRE 1N5Z-F T
L8 6200005640 S.COIL ELJRE 6N8Z-F T
L9 6200005610 S.COIL ELJRE 3N9Z-F T
L10 6200005580 S.COIL ELJRE 2N2Z-F T
L11 6200005640 S.COIL ELJRE 6N8Z-F B
S.=Surface mount
R1 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
except [EUR], [UK] T
7030009160 S.RESISTOR ERJ2GEJ 181 X (180 Ω) [EUR], [UK] T
R2 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω) T
R3 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R4 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R5 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R6 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) B
R7 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω) T
R8 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ) T
R9 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R10 7030004970 S.RESISTOR ERJ2GEJ 470 X (47 Ω) T
R11 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω) T
R12 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) T
R13 7030005300 S.RESISTOR ERJ2GEJ 150 X (15 Ω) T
R14 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ) B
R15 7030004990 S.RESISTOR ERJ2GEJ 221 X (220 Ω) B
R16 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω) B
R17 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R18 7030007280 S.RESISTOR ERJ2GEJ 331 X (330 Ω) B
R19 7030009270 S.RESISTOR ERJ2GEJ 821 X (820 Ω) B
R20 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) B
R21 7030005600 S.RESISTOR ERJ2GEJ 273 X (27 kΩ) T
R22 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R23 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R25 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R26 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) T
R27 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ) T
R28 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω) T
R29 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R30 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ) B
R31 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R32 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ) B
R33 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
C1 4030017620 S.CERAMIC ECJ0EC1H100C T
C2 4030017600 S.CERAMIC ECJ0EC1H080C T
C3 4030017580 S.CERAMIC ECJ0EC1H060C T
C4 4030017600 S.CERAMIC ECJ0EC1H080C T
C5 4030017730 S.CERAMIC ECJ0EB1E471K T
C6 4030017730 S.CERAMIC ECJ0EB1E471K T
C7 4030017340 S.CERAMIC ECJ0EC1H010B T
C8 4030017350 S.CERAMIC ECJ0EC1H020B T
C9 4030017350 S.CERAMIC ECJ0EC1H020B T
C10 4030017340 S.CERAMIC ECJ0EC1H010B T
C11 4030017460 S.CERAMIC ECJ0EB1E102K T
C12 4550007040 S.TANTALUM ECST0JZ106R T
C13 4030017400 S.CERAMIC ECJ0EC1H220J T
C14 4030016930 S.CERAMIC ECJ0EB1A104K B
C15 4030017730 S.CERAMIC ECJ0EB1E471K B
C16 4030017730 S.CERAMIC ECJ0EB1E471K B
C17 4030017730 S.CERAMIC ECJ0EB1E471K B
C18 4030017730 S.CERAMIC ECJ0EB1E471K B
C19 4030017730 S.CERAMIC ECJ0EB1E471K T
C21 4030017730 S.CERAMIC ECJ0EB1E471K B
C22 4550006910 S.TANTALUM TEESVP 1C 334M8R T
C23 4550007070 S.TANTALUM TEESVP 1A 475M8R B
C26 4030016930 S.CERAMIC ECJ0EB1A104K B
C27 4030017620 S.CERAMIC ECJ0EC1H100C T
C28 4030017340 S.CERAMIC ECJ0EC1H010B T
C29 4030017340 S.CERAMIC ECJ0EC1H010B T
C30 4030017350 S.CERAMIC ECJ0EC1H020B T
C31 4030017630 S.CERAMIC ECJ0EC1H120J T
C32 4030017400 S.CERAMIC ECJ0EC1H220J T
C34 4030017730 S.CERAMIC ECJ0EB1E471K T
C35 4030017730 S.CERAMIC ECJ0EB1E471K T
C36 4030017350 S.CERAMIC ECJ0EC1H020B T
C37 4030017730 S.CERAMIC ECJ0EB1E471K T
C38 4030017730 S.CERAMIC ECJ0EB1E471K T
C39 4030017340 S.CERAMIC ECJ0EC1H010B T
C40 4030017570 S.CERAMIC ECJ0EC1H040B T
C41 4030017640 S.CERAMIC ECJ0EC1H150J T
C42 4030017630 S.CERAMIC ECJ0EC1H120J T
C43 4030017730 S.CERAMIC ECJ0EB1E471K T
C44 4030017730 S.CERAMIC ECJ0EB1E471K B
C45 4030017360 S.CERAMIC ECJ0EC1H030B B
C46 4030017360 S.CERAMIC ECJ0EC1H030B B
C47 4030016790 S.CERAMIC ECJ0EB1C103K B
C48 4030016790 S.CERAMIC ECJ0EB1C103K B
C49 4030016790 S.CERAMIC ECJ0EB1C103K B
6 - 4
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
NO. NO.
[DOWNCONV BOARD]
