Icom IC-R5 Service Manual

S.=Surface mount
IC1 1140010860 S.IC M30220MA-121RP [USA]
1140010870 S.IC M30220MA-120RP except [USA]
IC2 1130011140 S.IC CAT24WC256K1.8
IC3 1110005820 S.IC R3112N281A-TR
IC100 1130007110 S.IC TC7W04FU (TE12L)
IC102 1110004790 S.IC XC6371A351PR
IC103 1180002370 S.REG R1111N321B-TR
IC104 1180002370 S.REG R1111N321B-TR
IC200 1110003800 S.IC NJM2904V-TE1
IC400 1110004520 S.IC M5222FP 600C
IC450 1190000710 S.IC TA31056F (TP1)
Q1 1590001940 S.TRANSISTOR DTC144EE TL
Q2 1590002150 S.TRANSISTOR DTC144TE TL
Q4 1590001940 S.TRANSISTOR DTC144EE TL
Q5 1530002280 S.TRANSISTOR 2SC4081 T106 S
Q100 1530002280 S.TRANSISTOR 2SC4081 T106 S
Q101 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q102 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q103 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q104 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q105 1590002430 S.TRANSISTOR DTA144EE TL
Q200 1590002430 S.TRANSISTOR DTA144EE TL
Q300 1530002280 S.TRANSISTOR 2SC4081 T106 S
Q301 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q302 1590001390 S.FET 2SJ144-Y (TE85R)
Q303 1590002430 S.TRANSISTOR DTA144EE TL
Q350 1590001390 S.FET 2SJ144-Y (TE85R)
Q400 1530002280 S.TRANSISTOR 2SC4081 T106 S
Q450 1590001170 S.TRANSISTOR XP1501-(TX) .AB
Q451 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q452 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q500 1590002950 S.FET HAT1023R-EL
Q501 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q502 1590001940 S.TRANSISTOR DTC144EE TL
D1 1790001250 S.DIODE MA2S111-(TX)
D2 1790001250 S.DIODE MA2S111-(TX)
D3 1730002510 S.ZENER MA8027-H (TX)
D100 1790001560 S.DIODE 1SS372 (TE85R)
D101 1790001560 S.DIODE 1SS372 (TE85R)
D102 1790001560 S.DIODE 1SS372 (TE85R)
D103 1790001560 S.DIODE 1SS372 (TE85R)
D105 1750000880 S.DIODE RB551V-30TE-17
D300 1790001250 S.DIODE MA2S111-(TX)
D301 1790000850 S.DIODE MA132WK (TX)
D500 1790000670 S.DIODE SB07-03C-TB
D501 1790001240 S.DIODE MA2S728-(TX)
D502 1750000880 S.DIODE RB551V-30TE-17
D503 1790000860 S.DIODE MA133 (TX)
X1 6060000800 S.CERAMIC CSTCR6M75G53
L100 6190001570 S.COIL CDRH5D28-101NC
R1 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R2 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R3 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ)
R4 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R5 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R6 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R7 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R8 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R9 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R10 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R11 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R12 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R13 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R14 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R15 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R16 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R17 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R18 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R19 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R20 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R21 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R22 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R23 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R24 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R25 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R26 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R27 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R28 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R29 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R30 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R31 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R32 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R33 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R34 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R35 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R36 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R37 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R38 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R39 7030004980 S.RESISTOR ERJ2GEJ 101 X (100 Ω)
R40 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R41 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R42 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R43 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R44 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R45 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R46 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R47 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R48 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R49 7030006610 S.RESISTOR ERJ2GEJ 394 X (390 kΩ)
R50 7030005100 S.RESISTOR ERJ2GEJ 154 X (150 kΩ)
R51 7030005230 S.RESISTOR ERJ2GEJ 334 X (330 kΩ)
R52 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ)
R53 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ)
R54 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R55 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R56 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R57 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R58 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R59 7030005580 S.RESISTOR ERJ2GEJ 560 X (56 Ω)
R61 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R62 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R63 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ)
R64 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R65 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R100 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
R101 7030007300 S.RESISTOR ERJ2GEJ 332 X (3.3 kΩ)
R102 7030005290 S.RESISTOR ERJ2GEJ 682 X (6.8 kΩ)
R103 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R104 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R105 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ)
R106 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R107 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R108 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R109 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R110 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R111 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R200 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R201 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ)
R202 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R203 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R204 7030005070 S.RESISTOR ERJ2GEJ 683 X (68 kΩ)
R205 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
R206 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
R207 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
R208 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R209 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ)
R300 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R301 7030007290 S.RESISTOR ERJ2GEJ 222 X (2.2 kΩ)
R302 7030009280 S.RESISTOR ERJ2GE
R303 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ)
R304 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ)
R305 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
