Icom IC-R5 Service Manual

6 - 2
S.=Surface mount
R306 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R307 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R308 7030008290 S.RESISTOR ERJ2GEJ 183 X (18 kΩ)
R309 7030008290 S.RESISTOR ERJ2GEJ 183 X (18 kΩ)
R310 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ)
R311 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R312 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R313 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R314 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ)
R315 7030008300 S.RESISTOR ERJ2GEJ 184 X (180 kΩ)
R316 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R317 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ)
R318 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
R319 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ)
R320 7030007350 S.RESISTOR ERJ2GEJ 393 X (39 kΩ)
R321 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R322 7030005720 S.RESISTOR ERJ2GEJ 563 X (56 kΩ)
R323 7030007350 S.RESISTOR ERJ2GEJ 393 X (39 kΩ)
R324 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R325 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R350 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R351 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R400 7030009290 S.RESISTOR ERJ2GEJ 562 X (5.6 kΩ)
R401 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ)
R402 7030005310 S.RESISTOR ERJ2GEJ 124 X (120 kΩ)
R403 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ)
R404 7030005210 S.RESISTOR ERJ2GEJ 822 X (8.2 kΩ)
R405 7030005060 S.RESISTOR ERJ2GEJ 333 X (33 kΩ)
R406 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
R407 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R408 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R409 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R450 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R451 7030005000 S.RESISTOR ERJ2GEJ 471 X (470 Ω)
R500 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R501 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R502 7030000090 S.RESISTOR MCR10EZHJ 3.9 Ω (3R9)
C1 4030017460 S.CERAMIC ECJ0EB1E102K
C2 4030016930 S.CERAMIC ECJ0EB1A104K
C3 4030017460 S.CERAMIC ECJ0EB1E102K
C4 4030017460 S.CERAMIC ECJ0EB1E102K
C5 4030017460 S.CERAMIC ECJ0EB1E102K
C6 4030017460 S.CERAMIC ECJ0EB1E102K
C7 4030017460 S.CERAMIC ECJ0EB1E102K
C8 4030017460 S.CERAMIC ECJ0EB1E102K
C9 4030017460 S.CERAMIC ECJ0EB1E102K
C10 4030017460 S.CERAMIC ECJ0EB1E102K
C11 4030017460 S.CERAMIC ECJ0EB1E102K
C12 4030017390 S.CERAMIC ECJ0EC1H180J
C13 4030017460 S.CERAMIC ECJ0EB1E102K
C14 4030017460 S.CERAMIC ECJ0EB1E102K
C17 4030017460 S.CERAMIC ECJ0EB1E102K
C18 4030017460 S.CERAMIC ECJ0EB1E102K
C20 4030017460 S.CERAMIC ECJ0EB1E102K
C21 4030017460 S.CERAMIC ECJ0EB1E102K
C22 4030017460 S.CERAMIC ECJ0EB1E102K
C23 4030017460 S.CERAMIC ECJ0EB1E102K
C24 4030017460 S.CERAMIC ECJ0EB1E102K
C25 4030017460 S.CERAMIC ECJ0EB1E102K
C26 4030017460 S.CERAMIC ECJ0EB1E102K
C27 4030017460 S.CERAMIC ECJ0EB1E102K
C28 4030017460 S.CERAMIC ECJ0EB1E102K
C29 4030017460 S.CERAMIC ECJ0EB1E102K
C30 4030017460 S.CERAMIC ECJ0EB1E102K
C31 4030017460 S.CERAMIC ECJ0EB1E102K
C32 4030017460 S.CERAMIC ECJ0EB1E102K
C34 4030017460 S.CERAMIC ECJ0EB1E102K
C35 4030017460 S.CERAMIC ECJ0EB1E102K
C40 4030017460 S.CERAMIC ECJ0EB1E102K
C43 4030016790 S.CERAMIC ECJ0EB1C103K
C45 4030016930 S.CERAMIC ECJ0EB1A104K
C46 4030017460 S.CERAMIC ECJ0EB1E102K
C47 4030017460 S.CERAMIC ECJ0EB1E102K
C48 4030017460 S.CERAMIC ECJ0EB1E102K
C49 4030017460 S.CERAMIC ECJ0EB1E102K
C51 4030017460 S.CERAMIC ECJ0EB1E102K
C53 4030017680 S.CERAMIC ECJ0EC1H820J
C100 4030017510 S.CERAMIC ECJ0EC1H680J
C101 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C102 4030017460 S.CERAMIC ECJ0EB1E102K
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
C103 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C104 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C105 4030017460 S.CERAMIC ECJ0EB1E102K
C106 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C107 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C108 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C109 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C110 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C113 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C114 4550006840 S.TANTALUM TEMSVA 1E 225M-8R
C115 4030011810 S.CERAMIC C1608 JB 1A 224K-T
C116 4030016930 S.CERAMIC ECJ0EB1A104K
C118 4550006320 S.TANTALUM ECST0JY475R
C120 4030017460 S.CERAMIC ECJ0EB1E102K
C121 4030017460 S.CERAMIC ECJ0EB1E102K
C123 4030017460 S.CERAMIC ECJ0EB1E102K
C126 4030017460 S.CERAMIC ECJ0EB1E102K
C127 4030017460 S.CERAMIC ECJ0EB1E102K
C128 4550006970 S.TANTALUM TEMSVA 0G 476M8R
C129 4550006620 S.TANTALUM ECST0JY226R
C130 4550006620 S.TANTALUM ECST0JY226R
C131 4510007970
S.ELECTROLYTIC ECEV1AA330WR
C132 4030017460 S.CERAMIC ECJ0EB1E102K
C133 4550006620 S.TANTALUM ECST0JY226R
C134 4550006250 S.TANTALUM TEMSVA 1A 106M-8L
C135 4510008040 S.ELECTROLYTIC EEFCD 0K 330R
C136 4030017460 S.CERAMIC ECJ0EB1E102K
C200 4030017460 S.CERAMIC ECJ0EB1E102K
C202 4030016930 S.CERAMIC ECJ0EB1A104K
C203 4030017440 S.CERAMIC ECJ0EC1H221J
C204 4030017460 S.CERAMIC ECJ0EB1E102K
C205 4030017910 S.CERAMIC ECJ0EB1H152K
C207 4030016970 S.CERAMIC ECJ0EB1C223K
C208 4030016970 S.CERAMIC ECJ0EB1C223K
C209 4030016790 S.CERAMIC ECJ0EB1C103K
C210 4030017490 S.CERAMIC C1608 JB 1A 105K-T
C301 4030016930 S.CERAMIC ECJ0EB1A104K
C303 4030016930 S.CERAMIC ECJ0EB1A104K
C304 4030016930 S.CERAMIC ECJ0EB1A104K
C305 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C306 4030016930 S.CERAMIC ECJ0EB1A104K
C307 4030017780 S.CERAMIC ECJ0EB1E472K
C308 4030016930 S.CERAMIC ECJ0EB1A104K
C309 4030017760 S.CERAMIC ECJ0EB1H222K
C310 4030017790 S.CERAMIC ECJ0EB1E682K
C311 4030017790 S.CERAMIC ECJ0EB1E682K
C312 4030016930 S.CERAMIC ECJ0EB1A104K
C313 4030016930 S.CERAMIC ECJ0EB1A104K
C314 4030016960 S.CERAMIC ECJ0EB1C183K
C315 4030016930 S.CERAMIC ECJ0EB1A104K
C316 4030016960 S.CERAMIC ECJ0EB1C183K
C317 4030016930 S.CERAMIC ECJ0EB1A104K
C318 4030016930 S.CERAMIC ECJ0EB1A104K
C319 4030016930 S.CERAMIC ECJ0EB1A104K
C320 4030016930 S.CERAMIC ECJ0EB1A104K
C321 4030016930 S.CERAMIC ECJ0EB1A104K
C322 4030016930 S.CERAMIC ECJ0EB1A104K
C351 4030016930 S.CERAMIC ECJ0EB1A104K
C352 4030016930 S.CERAMIC ECJ0EB1A104K
C400 4030016930 S.CERAMIC ECJ0EB1A104K
C401 4030008680 S.CERAMIC C2012 JF 1C 105Z-T
C402 4030016930 S.CERAMIC ECJ0EB1A104K
C403 4030016930 S.CERAMIC ECJ0EB1A104K
C404 4030016930 S.CERAMIC ECJ0EB1A104K
C405 4030016930 S.CERAMIC ECJ0EB1A104K
C406 4030017780 S.CERAMIC ECJ0EB1E472K
C450 4550006140 S.TANTALUM ECST1EY474R
C451 4550002950 S.TANTALUM TESVA 0J 335M1-8L
C452 4550006550 S.TANTALUM TEMSVD 0G 227M-12R
C453 4510007970
S.ELECTROLYTIC ECEV1AA330WR
C454 4030016930 S.CERAMIC ECJ0EB1A104K
C455 4030016930 S.CERAMIC ECJ0EB1A104K
C456 4030017430 S.CERAMIC ECJ0EC1H101J
C457 4550006320 S.TANTALUM ECST0JY475R
C458 4550006320 S.TANTALUM ECST0JY475R
C500 4030017460 S.CERAMIC ECJ0EB1E102K
C501 4030017460 S.CERAMIC ECJ0EB1E102K
C503 4030017460 S.CERAMIC ECJ0EB1E102K
C504 4030017460 S.CERAMIC ECJ0EB1E102K
C505 4030017780 S.CERAMIC ECJ0EB1E472K
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
