Icom IC-R5 - Page 24

S.=Surface mount
J2 6450002010 S.CONNECTOR HSJ1501-011010
J3 6510020560 S.CONNECTOR AXK5S40340P
J500 6450002130 CONNECTOR 04-730A1-02BKA
DS1 5030001990 LCD TTR5169 UPFDHW
S6 2250000390 ENCODER TP90N00E20-16F-1995
S9 2230001070 S.SWITCH JPM1990-2711R
S10 2230001070 S.SWITCH JPM1990-2711R
W2 7030010040 S.JUMPER ERJ2GE-JPW [EUR], [FRA] only
W3 7030010040 S.JUMPER ERJ2GE-JPW [USA], [UK] only
W4 7030010040 S.JUMPER ERJ2GE-JPW
[USA], [FRA], [ESP] only
W5 7030010040 S.JUMPER ERJ2GE-JPW
except [EUR], [UK], [USA]
W7 7030010040 S.JUMPER ERJ2GE-JPW [FRA] only
W14 7030010040 S.JUMPER ERJ2GE-JPW
W16 7030003860 S.JUMPER ERJ3GE JPW V
W17 7030010040 S.JUMPER ERJ2GE-JPW
W200 7030010040 S.JUMPER ERJ2GE-JPW
W600 9026050001 WIRE 71/98/036/X98/X98
EP1 6910012350 S.BEAD MMZ1608Y 102BT
EP2 6910012350 S.BEAD MMZ1608Y 102BT
EP3 6910014600 E.OTHER CV1071 RX2605
EP4 8930058920 LCD CONTACT SRCN-2605-SP-N-W
EP5 0910055724 PCB B 5887D
EP9 6910013310 S.BEAD MMZ1608D121B
EP10 6910014680 S.BEAD MMZ1608Y 121BT
EP11 6910014680 S.BEAD MMZ1608Y 121BT
EP12 6910014690 S.BEAD MPZ1608S221A-T
EP13 6910014690 S.BEAD MPZ1608S221A-T
IC1 1110005230 S.IC µPC2757TB-E3
IC2 1110003200 S.IC TA31136FN (EL)
IC3 1130007610 S.IC µPD3140GS-E1 (DS8)
IC4 1110005180 S.IC µPC2746TB-E3
IC10 1110005230 S.IC µPC2757TB-E3
IC11 1110005180 S.IC µPC2746TB-E3
Q1 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q2 1560000540 S.FET 2SK880-Y (TE85R)
Q4 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q5 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q6 1530003610 S.TRANSISTOR FH102-TL
Q14 1530003610 S.TRANSISTOR FH102-TL
Q24 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q26 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q28 1530003260 S.TRANSISTOR 2SC5006-T1
Q29 1590001940 S.TRANSISTOR DTC144EE TL
Q30 1530003260 S.TRANSISTOR 2SC5006-T1
Q31 1530003610 S.TRANSISTOR FH102-TL
Q33 1590001810 S.TRANSISTOR XP1113 (TX)
Q35 1590002650 S.TRANSISTOR UPA805T-T1
Q36 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q37 1530003630 S.TRANSISTOR 2SC4617 TLS
Q40 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q41 1590002430 S.TRANSISTOR DTA144EE TL
Q43 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q44 1590001660 S.TRANSISTOR XP4312 (TX)
Q45 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R)
Q46 1590001660 S.TRANSISTOR XP4312 (TX)
Q501 1590002430 S.TRANSISTOR DTA144EE TL
Q502 1590001810 S.TRANSISTOR XP1113 (TX)
Q503 1590001810 S.TRANSISTOR XP1113 (TX)
Q504 1590001810 S.TRANSISTOR XP1113 (TX)
Q505 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
6 - 3
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
Q506 1590002430 S.TRANSISTOR DTA144EE TL
Q507 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q508 1590001660 S.TRANSISTOR XP4312 (TX)
Q509 1590002430 S.TRANSISTOR DTA144EE TL
Q510 1590001540 S.TRANSISTOR UMD6N TR
Q513 1590001650 S.TRANSISTOR XP4601 (TX)
Q514 1590001540 S.TRANSISTOR UMD6N TR
Q515 1590001940 S.TRANSISTOR DTC144EE TL
D1 1720000780 S.VARICAP HVU350B TRF
D2 1720000780 S.VARICAP HVU350B TRF
D3 1790001620 S.DIODE 1SV308 (TPL3)
D4 1720000780 S.VARICAP HVU350B TRF
D5 1720000780 S.VARICAP HVU350B TRF
D11 1790001620 S.DIODE 1SV308 (TPL3)
D13 1790001620 S.DIODE 1SV308 (TPL3)
D17 1720000700 S.VARICAP 1SV305 (TPL3)
D18 1720000780 S.VARICAP HVU350B TRF
D20 1790001590 S.DIODE MA6S718 (TX)
D21 1790001590 S.DIODE MA6S718 (TX)
D25 1790001620 S.DIODE 1SV308 (TPL3)
D29 1790001620 S.DIODE 1SV308 (TPL3)
D31 1790000850 S.DIODE MA132WK (TX)
D32 1790001620 S.DIODE 1SV308 (TPL3)
D34 1790001620 S.DIODE 1SV308 (TPL3)
D36 1790001620 S.DIODE 1SV308 (TPL3)
D42 1790001260 S.DIODE MA2S077-(TX)
D43 1790001260 S.DIODE MA2S077-(TX)
D44 1790001260 S.DIODE MA2S077-(TX)
D46 1790001260 S.DIODE MA2S077-(TX)
D47 1790001620 S.DIODE 1SV308 (TPL3)
D50 1790001620 S.DIODE 1SV308 (TPL3)
D52 1790001620 S.DIODE 1SV308 (TPL3)
D53 1790001250 S.DIODE MA2S111-(TX)
D54 1720000650 S.VARICAP 1SV286 (TPH3)
D55 1790000850 S.DIODE MA132WK (TX)
D56 1790000850 S.DIODE MA132WK (TX)
D57 1790000660 S.DIODE MA728 (TX)
D58 1790001260 S.DIODE MA2S077-(TX)
D59 1790001260 S.DIODE MA2S077-(TX)
D60 1790001260 S.DIODE MA2S077-(TX)
D61 1790001260 S.DIODE MA2S077-(TX)
D62 1790000660 S.DIODE MA728 (TX)
D63 1790001260 S.DIODE MA2S077-(TX)
D64 1790001260 S.DIODE MA2S077-(TX)
D65 1790001260 S.DIODE MA2S077-(TX)
D66 1790001260 S.DIODE MA2S077-(TX)
D67 1790001260 S.DIODE MA2S077-(TX)
D68 1720000240 S.DIODE 1SV172 (TE85R)
D69 1790001260 S.DIODE MA2S077-(TX)
D70 1790001260 S.DIODE MA2S077-(TX)
D71 1790001620 S.DIODE 1SV308 (TPL3)
D72 1790001620 S.DIODE 1SV308 (TPL3)
D73 1790001620 S.DIODE 1SV308 (TPL3)
D74 1790001620 S.DIODE 1SV308 (TPL3)
D75 1790001620 S.DIODE 1SV308 (TPL3)
D76 1790001260 S.DIODE MA2S077-(TX)
D100 1720000820 S.VARICAP SVC347S/T-TL
D101 1790001260 S.DIODE MA2S077-(TX)
FI1 2040001200 S.SAW EFCH266MKQP1
FI2 2020001270 CERAMIC CFWLB450KE2A-B0 (CFWM450E)
FI3 2010002280 S.MONOLITH FL-293 (19.650 MHz)
X1 6050010210 S.XTAL CR-593 (19.200 MHz)
L1 6200007740 S.COIL
LQW2BHN47NJ01L (LQN21A 47NJ04)
L2 6200005720 S.COIL ELJRE 33NG-F
L3 6200005700 S.COIL ELJRE 22NG-F
L4 6200005700 S.COIL ELJRE 22NG-F
L5 6200005680 S.COIL ELJRE 15NG-F
L7 6200005710 S.COIL ELJRE 27NG-F
L8 6200005630 S.COIL ELJRE 5N6Z-F
L9 6200005720 S.COIL ELJRE 33NG-F
L10 6200005700 S.COIL ELJRE 22NG-F
L11 6200005680 S.COIL ELJRE 15NG-F
L12 6200005660 S.COIL ELJRE 10NG-F
L13 6200005630 S.COIL ELJRE 5N6Z-F
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
