Icom IC-R5 Service Manual

6 - 6
S.=Surface mount
C176 4030017420 S.CERAMIC ECJ0EC1H470J
C178 4030017460 S.CERAMIC ECJ0EB1E102K
C180 4030017460 S.CERAMIC ECJ0EB1E102K
C182 4030017460 S.CERAMIC ECJ0EB1E102K
C183 4030017550 S.CERAMIC ECJ0EC1H1R5B
C186 4030017460 S.CERAMIC ECJ0EB1E102K
C188 4030017460 S.CERAMIC ECJ0EB1E102K
C190 4030017360 S.CERAMIC ECJ0EC1H030B
C191 4030017570 S.CERAMIC ECJ0EC1H040B
C192 4030017590 S.CERAMIC ECJ0EC1H070C
C193 4030017630 S.CERAMIC ECJ0EC1H120J
C194 4030017670 S.CERAMIC ECJ0EC1H390J
C195 4030017550 S.CERAMIC ECJ0EC1H1R5B
C196 4030017360 S.CERAMIC ECJ0EC1H030B
C197 4030017380 S.CERAMIC ECJ0EC1H050B
C198 4030017610 S.CERAMIC ECJ0EC1H090C
C199 4030017650 S.CERAMIC ECJ0EC1H270J
C200 4030016790 S.CERAMIC ECJ0EB1C103K
C201 4030016930 S.CERAMIC ECJ0EB1A104K
C202 4030016930 S.CERAMIC ECJ0EB1A104K
C203 4030016930 S.CERAMIC ECJ0EB1A104K
C206 4030017370 S.CERAMIC ECJ0EC1H3R5B
C207 4030017660 S.CERAMIC ECJ0EC1H330J
C208 4030017420 S.CERAMIC ECJ0EC1H470J
C209 4030017460 S.CERAMIC ECJ0EB1E102K
C210 4550000530 S.TANTALUM TESVA 1V 104M1-8L
C211 4030017460 S.CERAMIC ECJ0EB1E102K
C214 4030017460 S.CERAMIC ECJ0EB1E102K
C216 4030017630 S.CERAMIC ECJ0EC1H120J
C218 4030017340 S.CERAMIC ECJ0EC1H010B
C221 4030016790 S.CERAMIC ECJ0EB1C103K
C233 4030017460 S.CERAMIC ECJ0EB1E102K
C234 4030017460 S.CERAMIC ECJ0EB1E102K
C235 4030017460 S.CERAMIC ECJ0EB1E102K
C236 4030017460 S.CERAMIC ECJ0EB1E102K
C237 4030017460 S.CERAMIC ECJ0EB1E102K
C239 4030016790 S.CERAMIC ECJ0EB1C103K
C241 4030011810 S.CERAMIC C1608 JB 1A 224K-T
C242 4030011810 S.CERAMIC C1608 JB 1A 224K-T
C243 4030017390 S.CERAMIC ECJ0EC1H180J
C244 4030017380 S.CERAMIC ECJ0EC1H050B
C248 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C249 4030016790 S.CERAMIC ECJ0EB1C103K
C250 4030017600 S.CERAMIC ECJ0EC1H080C
C251 4030017570 S.CERAMIC ECJ0EC1H040B
C252 4030017600 S.CERAMIC ECJ0EC1H080C
C256 4030017460 S.CERAMIC ECJ0EB1E102K
C257 4030017460 S.CERAMIC ECJ0EB1E102K
C258 4030017460 S.CERAMIC ECJ0EB1E102K
C259 4030017430 S.CERAMIC ECJ0EC1H101J
C264 4030017460 S.CERAMIC ECJ0EB1E102K
C402 4030017460 S.CERAMIC ECJ0EB1E102K
C410 4030017460 S.CERAMIC ECJ0EB1E102K
C414 4030017460 S.CERAMIC ECJ0EB1E102K
C416 4030017650 S.CERAMIC ECJ0EC1H270J
C417 4030017420 S.CERAMIC ECJ0EC1H470J
C423 4550003220 S.TANTALUM TEMSVA 1E 105M-8L
C424 4030016790 S.CERAMIC ECJ0EB1C103K
C427 4030017400 S.CERAMIC ECJ0EC1H220J
C429 4030016790 S.CERAMIC ECJ0EB1C103K
C430 4030016790 S.CERAMIC ECJ0EB1C103K
C431 4030016790 S.CERAMIC ECJ0EB1C103K
C432 4030017460 S.CERAMIC ECJ0EB1E102K
C433 4030017460 S.CERAMIC ECJ0EB1E102K
C434 4030016930 S.CERAMIC ECJ0EB1A104K
C435 4030017460 S.CERAMIC ECJ0EB1E102K
C436 4030017360 S.CERAMIC ECJ0EC1H030B
C503 4030017460 S.CERAMIC ECJ0EB1E102K
C504 4030017460 S.CERAMIC ECJ0EB1E102K
C505 4030017460 S.CERAMIC ECJ0EB1E102K
C507 4030017700 S.CERAMIC ECJ0EC1H151J
C510 4030017350 S.CERAMIC ECJ0EC1H020B
C511 4030017660 S.CERAMIC ECJ0EC1H330J
C512 4030017660 S.CERAMIC ECJ0EC1H330J
C513 4030017680 S.CERAMIC ECJ0EC1H820J
C514 4030017700 S.CERAMIC ECJ0EC1H151J
C515 4030017430 S.CERAMIC ECJ0EC1H101J
C516 4030017440 S.CERAMIC ECJ0EC1H221J
C517 4030017710 S.CERAMIC ECJ0EC1H181J
C518 4030017460 S.CERAMIC ECJ0EB1E102K
C519 4030017910 S.CERAMIC ECJ0EB1H152K
C520 4030016790 S.CERAMIC ECJ0EB1C103K
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
C521 4030016930 S.CERAMIC ECJ0EB1A104K
C522 4030016790 S.CERAMIC ECJ0EB1C103K
C523 4030017910 S.CERAMIC ECJ0EB1H152K
C524 4030016790 S.CERAMIC ECJ0EB1C103K
C525 4030016790 S.CERAMIC ECJ0EB1C103K
C526 4030016940 S.CERAMIC ECJ0EB1A393K
C527 4030017680 S.CERAMIC ECJ0EC1H820J
C528 4030017650 S.CERAMIC ECJ0EC1H270J
C529 4030017700 S.CERAMIC ECJ0EC1H151J
C530 4030017720 S.CERAMIC ECJ0EB1H331K
C531 4030017710 S.CERAMIC ECJ0EC1H181J
C532 4030016930 S.CERAMIC ECJ0EB1A104K
C534 4030017720 S.CERAMIC ECJ0EB1H331K
C535 4030017460 S.CERAMIC ECJ0EB1E102K
C536 4030016930 S.CERAMIC ECJ0EB1A104K
C537 4030016930 S.CERAMIC ECJ0EB1A104K
C538 4030016930 S.CERAMIC ECJ0EB1A104K
C539 4030016930 S.CERAMIC ECJ0EB1A104K
C540 4030016930 S.CERAMIC ECJ0EB1A104K
C541 4030016930 S.CERAMIC ECJ0EB1A104K
C542 4030016930 S.CERAMIC ECJ0EB1A104K
C543 4030017460 S.CERAMIC ECJ0EB1E102K
C544 4030017460 S.CERAMIC ECJ0EB1E102K
C545 4030016790 S.CERAMIC ECJ0EB1C103K
C546 4030016930 S.CERAMIC ECJ0EB1A104K
C548 4030017460 S.CERAMIC ECJ0EB1E102K
C550 4030017600 S.CERAMIC ECJ0EC1H080C
C554 4030017420 S.CERAMIC ECJ0EC1H470J
C558 4030017460 S.CERAMIC ECJ0EB1E102K
C560 4030017460 S.CERAMIC ECJ0EB1E102K
C561 4030017460 S.CERAMIC ECJ0EB1E102K
C562 4030017460 S.CERAMIC ECJ0EB1E102K
C563 4030017460 S.CERAMIC ECJ0EB1E102K
C566 4030016790 S.CERAMIC ECJ0EB1C103K
C567 4030016930 S.CERAMIC ECJ0EB1A104K
C568 4030017420 S.CERAMIC ECJ0EC1H470J
C569 4030016930 S.CERAMIC ECJ0EB1A104K
C570 4030017460 S.CERAMIC ECJ0EB1E102K
C571 4030017460 S.CERAMIC ECJ0EB1E102K
C654 4030011810 S.CERAMIC C1608 JB 1A 224K-T
C655 4550000510 S.TANTALUM TESVA 1V 473M1-8L
C656 4030017600 S.CERAMIC ECJ0EC1H080C
C657 4030018100 S.CERAMIC ECJ0EB1H681K
C658 4030017760 S.CERAMIC ECJ0EB1H222K
C659 4550006200 S.TANTALUM ECST0JY106R
C662 4030016930 S.CERAMIC ECJ0EB1A104K
C663 4030016930 S.CERAMIC ECJ0EB1A104K
C664 4030016930 S.CERAMIC ECJ0EB1A104K
C665 4030017430 S.CERAMIC ECJ0EC1H101J
C666 4030018140 S.CERAMIC ECJ0EB1H391K
C667 4030016790 S.CERAMIC ECJ0EB1C103K
C668 4030016790 S.CERAMIC ECJ0EB1C103K
C669 4030017460 S.CERAMIC ECJ0EB1E102K
C671 4030017460 S.CERAMIC ECJ0EB1E102K
C672 4030017460 S.CERAMIC ECJ0EB1E102K
C673 4030017460 S.CERAMIC ECJ0EB1E102K
C674 4030017420 S.CERAMIC ECJ0EC1H470J
C675 4030016930 S.CERAMIC ECJ0EB1A104K
C676 4030017400 S.CERAMIC ECJ0EC1H220J
J1 6510020120 S.CONNECTOR AXK6S40545P
EP1 0910055732 PCB B 5886B
EP2 3310003010 ANTENNA KY-058-006-2 <KAI>
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
