S.=Surface mount
D10 1750000710 S.VARICAP HVC350BTRF
D11 1750000710 S.VARICAP HVC350BTRF
D12 1710001060 DIODE XB15A407
D13 1750000710 S.VARICAP HVC350BTRF
D14 1790000980 S.DIODE MA742 (TX)
D15 1750000550 S.DIODE 1SS355 TE-17
D16 1710000870 S.DIODE HVU131TRF
D17 1790000980 S.DIODE MA742 (TX)
D18 1790001250 S.DIODE MA2S111-(TX)
D19 1710001080 DIODE XB15A308
D20 1730000520 ZENER RD20E B2
D21 1790000700 DIODE DSA3A1
D22 1790001520 S.ZENER MA8075-L (TX)
D23 1790001250 S.DIODE MA2S111-(TX) [USA] only
D24 1790001250 S.DIODE MA2S111-(TX) [USA] only
D25 1790001250 S.DIODE MA2S111-(TX) [USA] only
D26 1790001250 S.DIODE MA2S111-(TX) [USA] only
D27 1710001060 DIODE XB15A407
D28 1790000980 S.DIODE MA742 (TX)
D29 1750000370 S.DIODE DA221 TL
FI1 2020001520 CERAMIC CFWLA450KFFA-B0 (CFWS450F)
FI2 2020001460 CERAMIC CFWLA450KHFA-B0 (CFWS450HT)
[USA] only
FI3 2010002420 MONOLITH 21R15AB (FL-310)
FI4 2010002420 MONOLITH 21R15AB (FL-310)
X1 6050010800 S.XTAL CR-659 (21.25 MHz)
X2 6070000200
DISCRIMINATOR
CDBLA450KCAY24-B0
L1 6200004480 S.COIL MLF1608D R82K-T
L2 6200002850 S.COIL NL 252018T-R82J
L3 6200001620 S.COIL ELJFC 1R0K-F
L6 6200009920 S.COIL C2012C-R10G
L7 6200009910 S.COIL C6342A-88NG-A
L8 6200004870 S.COIL ELJFC 2R7K-F
L9 6200004880 S.COIL ELJFC 3R3K-F
L10 6200001620 S.COIL ELJFC 1R0K-F
L11 6200006980 S.COIL ELJRE R10G-F
L12 6200006980 S.COIL ELJRE R10G-F
L13 6200006980 S.COIL ELJRE R10G-F
L14 6200006990 S.COIL ELJRE 56NG-F
L15 6200007000 S.COIL ELJRE 82NG-F
L18 6200005740 S.COIL ELJRE 47NG-F
L19 6200004920 S.COIL MLF1608A 2R2K-T
L20 6200005740 S.COIL ELJRE 47NG-F
L21 6200006980 S.COIL ELJRE R10G-F
L22 6200006670 S.COIL ELJRE 68NG-F
L23 6200005680 S.COIL ELJRE 15NG-F
L24 6200003590 S.COIL EXCCL3225U1
L25 6200003280 S.COIL NL 252018T-2R2J
L26 6200003280 S.COIL NL 252018T-2R2J
L27 6200003590 S.COIL EXCCL3225U1
L28 6200008260 S.COIL 0.30-1.7-8TL 60N
L30 6200008490 S.COIL 0.30-0.9-3TR 7.5N
L31 6200009930 S.COIL C2012C-68NG
L32 6200009930 S.COIL C2012C-68NG
L33 2040000490 COIL EXC-ELDR25C
L34 2040000490 COIL EXC-ELDR25C
L35 6110001680 COIL LA-254
L37 6200010040 S.COIL AS100340-10N
L38 6200009920 S.COIL C2012C-R10G
L39 6200010050 S.COIL AS080547-47N
L40 6170000180 COIL LW-19
L42 6200007370 S.COIL ELJFC R82K-F
L43 6200009750 S.COIL 0.30-2.0-7TL 68N
L44 6200010050 S.COIL AS080547-47N
L45 6200008150 S.COIL 0.35-1.6-7TL 44N
L46 6200010060 S.COIL AS080647-56N
L47 6200010070 S.COIL AS080747-68N
L48 6200010070 S.COIL AS080747-68N
L50 6200002910 S.COIL NL 252018T-R27J
L51 6200010050 S.COIL AS080547-47N
L52 6200002180 S.COIL NL 252018T-R12J
L53 6200005710 S.COIL ELJRE 27NG-F
R1 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R2 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
5 - 3
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
R3 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ)
R4 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω)
R5 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R6 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R7 7510001280 S.THERMISTOR NTCCM20124AG473J-T
R8 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R10 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R11 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R12 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R13 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R14 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R15 7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ)
R16 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R17 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R18 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R19 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R20 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ)
R21 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R22 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R23 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R24 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R25 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R26 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R27 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
R28 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R29 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R30 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R31 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R32 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R33 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω)
R34 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R35 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω)
R36 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R37 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R39 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R40 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R41 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R42 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R43 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R44 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R45 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R46 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R47 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R48 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R49 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R50 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R51 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R52 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R54 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω)
R55 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R56 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R57 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R58 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R59 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R60 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R62 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R63 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R64 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R66 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R67 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R68 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R69 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R71 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R72 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R73 7030003470 S.RESISTOR ERJ3GEYJ 182 V (1.8 kΩ)
[SEA], [CSA]
7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ) [USA]
R76 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R78 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R79 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R81 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R82 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R83 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R84 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R88 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R90 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R92 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R93 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R95 7030000230 S.RESISTOR MCR10EZHJ 56 Ω (560)
R96 7030000660 S.RESISTOR MCR10EZHJ 220 kΩ
R98 7030009980 S.RESISTOR ERJ12RSJR15U
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
