ICON PLATFORM NANO User Manual

62
<<<<<<<<<Mix and Transport>>>>>>>>>
Jog Wheel:
Turn the Jog Wheel to quickly adjust the playhead position on the grid, visible in the Arrange
Window in Logic Pro X.
Scrub= Toggle Scrub: appliesto the Jog Wheel
Shift + Scrub = Toggle Shuttle: turn the Jog Wheel to adjust playback speed
Play - Scrub = Pause playback
There are options in Logic Pro X for scrubbing:
Preferences -> Audio -> Editing
To enable audio scrub in Logic Pro X, select “Scrubbing with audio…”
(On Platform M+, scrub is activated by pressing down the jog wheel.)
Transport:
The Transportsection is used to operate playback.
Play = Begin playback
Stop = Stop playback

ICON PLATFORM NANO Specifications

General

Connectivity	USB
Compatibility	Windows, macOS
Power Supply	USB Bus Powered
Transport Controls	Yes
USB	USB 2.0
Footswitch	1 footswitch connector
Inputs	1 x Footswitch
Faders	1 x Touch-sensitive motorized fader with 10-bit resolution
Display	12-segment LED display
