©2017 ICS - Blount Inc, Specications subject to change without notice. REV19JUNE2017 P/N 598901
22
695XL SERVICE MANUAL
7.SIDE COVER & TENSIONER
7.4
Inspect side cover, nut and circlip.
Replace if damaged.
Circlip can be removed with a large
athead screwdriver.
7.5
Assemble in reverse order.
