ICS 695XL Service Manual

©2017 ICS - Blount Inc, Specications subject to change without notice. REV19JUNE2017 P/N 598901
5
695XL SERVICE MANUAL
2. SPECIFICATIONS
Engine Type 2-stroke, Air Cooled
Displacement 94 cc (5.7 cu-in)
Horsepower 4.8 kW (6.4 hp) @ 9000 rpm
Torque 5.7 Nm (50.4 in-lbs) @ 7,200 rpm
Engine Speed
9,300 +/- 150 rpm (max)
2,700 +/- 100 rpm (idle)
Chain Speed at Maximum Power 28 m/s (5500 ft/min)
Weight 9.5 kg (21 lbs) powerhead only
Dimensions
46 cm (18 in) length 36 cm (14 in) height
30 cm (12 in) width
Air Filter Water resistant polyester
Carburetor Walbro RWJ-7
Starter Recoil, dust and water resistant
Ignition Special water resistant electronic ignition
Clutch Centrifugal, three shoe, three spring
Fuel ratio 2% (50:1) petrol-to-oil
Fuel Capacity 1 liter (0.26 gallon)
Water Supply Requirement Minimum 1.5 bar (20 psi)
Water Flow Requirement Minimum: 4lpm (1 gpm )
Guaranteed Sound Power Level, L
wa
(1)
115 dB(A); (K
wa
=1.0 dB(A))
Equivalent Sound Pressure at the
Operator's Ear L
pA
104.6 dB(A) (K=1.0 dB(A))
Vibration, a
hv, eq
Concrete Cutting (2)
3.6 m/s
2
(K=1.0 m/s
2
) Front Handle
3.1 m/s
2
(K=1.0 m/s
2
) Rear Handle
Vibration, a
hv, eq
Pipe Cutting (2)
5.62 m/s
2
(K=0.2 m/s
2
) Front Handle
5.28 m/s
2
(K=0.2 m/s
2
) Rear Handle
Engine Break-in Period One tank, without cutting, cycling throttle
Spark Plug
NGK BPMR7A or Champion RCJ6Y
Electrode gap 0.5 mm (0.020 in)
(1) Measured in accordance with ANSI S12.51-2012/ISO3741:2010
(2) Measured in accordance with ISO5349-1:2001, ISO22867:2011 and ISO19432:2012
