695XL SERVICE MANUAL

25.2

With the carburetor and muer removed,

block the intake and exhaust ports with

the seal anges.

See Cylinder Cover and Muer

sections.

NOTE: Remove intake plate from

intake boot prior to installing intake seal

ange.

A B

25.3

Securely plug or tape over the clutch

needle roller lubrication port on the

crankshaft.

Clutch cup and needle roller must be

removed. See Clutch Cup and Rim

Sprocket Section (section 8).

25.1

A.) Exhaust Seal Flange.

B.) Intake Seal Flange.

25. This section covers testing the crankcase for leaks. A crankcase leak can

cause the engine to run too lean, causing engine damage, or not run at all.

25. CRANKCASE LEAKS
