695XL SERVICE MANUAL

7. This section covers side cover removal, side cover nut removal,

inspection and assembly.

7.1

Loosen side cover nut.

• Remove side cover.

• Remove tensioner plate screws and

tensioner plate.

7.2

Remove tensioner assembly.

Note the orientation of the tensioner

assembly.

7.3

Inspect tensioner and replace if needed.

• Clean tensioner threads and liberally

apply grease to threads prior to

assembly.

7.SIDE COVER & TENSIONER
