ICT PRX-TSEC User Manual

Enable OSDP
The following programming example demonstrates how to create a config card that enables the tSec Reader to
use the OSDPcommunication protocol.
1. Log in to the ICT Encoder Client using your secure operator login.
2. Select the required Customer.
3. Right click the Reader Configuration component and create a New Config called OSDP Output Mode.
4. Click the Import button to create a custom format.
5.
In the Custom Format field, enter the OSDP Output Mode Hex code 0B0104.
6. Save the custom format, then Save your configuration.
7. Right click your new OSDP Output Mode config and click Encode.
8. Place your blank MIFARE Classic card on the desktop encoder.
9. Click Write Config and wait for the 'programming success' message.
You can now apply the configuration to the required reader(s). Power cycle the reader, and within two minutes
place and hold the OSDP Output Mode config card close to the reader.
For more information on configuring OSDP, see AN-321: Configuring tSec Readers for OSDP Communication.
ISO14443 Gain forDESFire EV2 Tags
To read DESFire EV2 tags, the ISO14443 gain should be set to 6. Some tSec Reader firmware versions do not
contain the required ISO14443 gain configuration by default, so it is necessary to program the configuration.
1. Log in to the ICT Encoder Client using your secure operator login.
2. Select the required Customer.
3. Right click the Reader Configuration component and create a New Config called ISO14443 Gain for EV2
Tags.
4. Click the Import button to create a custom format.
5.
In the Custom Format field, enter the ISO14443 Gain 6 Hex code 180106.
6. Save the custom format, then Save your configuration.
7. Right click your new ISO14443 Gain for EV2 Tags config and click Encode.
8. Place your blank MIFARE Classic card on the desktop encoder.
9. Click Write Config and wait for the 'programming success' message.
You can now apply the configuration to the required reader(s). Power cycle the reader, and within two minutes
place and hold the ISO14443 Gain for EV2 Tags config card close to the reader.
For detailed information on programming config cards using the Encoder Client, including the available
configuration settings, refer to the ICT Encoder Client User Guide.
PRX-TSEC Range | tSec Multi-Technology Card Reader with Bluetooth® Technology | Installation Manual 22
