7
Installation and Servicing
SECTION 1 - GENERAL
Table 2 - Performance Data
The Indirect products within this range are BESA tested. Test reports can be found at www.thebesa.com/ukhiu
Direct central heating performance is dependent on primary operating conditions.
Models
Indirect Direct
POD
i305
POD
i405
POD
i505
POD
i605
POD
i705
POD
D30
POD
D40
POD
D50
POD
D60
Primary Supply Temperature @ 50kPa 70°C
Primary Flow Rate l/s
0.188 0.265 0.314 0.310 0.319 0.188 0.265 0.314 0.310
Primary Return Temperature °C
30.3 31.7 30.0 25.1 22.0 30.3 31.7 30.0 25.1
Primary Pressure Drop kPa
52 51 48 51 54 52 51 48 51
DHW Flow Rate
(60°C @ 50K rise)
l/min
9.3 11.9 15.4 19.4 24.5 9.3 11.9 15.4 19.4
DHW Output (60°C @ 50K rise) kW
30.6 41.0 50.7 54.9 61.6 30.6 41.0 50.7 54.9
Primary Flow Rate l/s
0.16 0.23 0.27 0.31 0.33 0.16 0.23 0.27 0.31
Primary Return Temperature °C
24.3 27.1 25.9 18.6 23.0 24.3 27.1 25.9 18.6
Primary Pressure Drop kPa
51 50 53 49 59 51 50 53 49
DHW Flow Rate
(55°C @ 45K rise)
l/min
9.7 13.3 16.7 19.0 22.4 9.7 13.3 16.7 19.0
DHW Output (55°C @ 45K rise) kW
30.7 39.9 50.6 57.9 63.4 30.7 39.9 50.6 57.9
Primary Flow Rate l/s
0.16 0.21 0.26 0.29 0.32 0.16 0.21 0.26 0.29
Primary Return Temperature °C
22.7 23.57 22.85 23.2 22.3 22.7 23.57 22.85 23.2
Primary Pressure Drop kPa
53 51 51 54 55 53 51 51 54
DHW Flow Rate
(50°C @ 40K rise)
l/min
11.6 14.9 18.4 21.3 25.5 11.6 14.9 18.4 21.3
DHW Output (50°C @ 45K rise) kW
31.0 39.3 50.6 56.9 63.9 31.0 39.3 50.6 56.9
Primary Flow Rate l/s
0.12 0.18 0.22 0.26 0.29 0.12 0.18 0.22 0.26
Primary Return Temperature °C
18.2 20.3 19.2 20.4 20.8 18.2 20.3 19.2 20.4
Primary Pressure Drop kPa
57 52 48 47 50 57 52 48 47
DHW Flow Rate
(45°C @ 35K rise)
l/min
11.1 15.3 19.5 21.8 24.6 11.1 15.3 19.5 21.8
DHW Output (45°C @ 35K rise) kW
26.4 35.3 46.9 51.1 58.4 26.4 35.3 46.9 51.1
CH Flow Rate (65°C - 35°C) l/min
4.29 N/A
CH Output (65°C - 35°C) kW
6.4 N/A
CH Flow Rate (70°C - 40°C) l/min
4.07 N/A
CH Output (70°C - 40°C) kW
5.29 N/A
ELECTRICAL
Electrical Power Supply Voltage AC Voltage
230
Frequency Hz
50
Maximum Power Consumption W
53.1 8.6
Standby Power Consumption W
2.8
Appliance Protection Rating IP
20
Sound Power Level Indoors (L
WA
) dB
48.6 37.9
