Option Kits
Boiler CXSi/H
Volt free contacts, alarm & boiler run conditions ✓
• Ultra reliable gas atmospheric boilers
• High, full and part load efficiencies -
meets Building Regulations 2006 (Part L2)
• Auto ignition
• Remote indication kit options
• High/Low operation
Model 110/H 120/H 140/H 160/H 180/H
Sections 778910
Output (kW) 110 120 140 160 180
Height 1000
Width 1107 1107 1230 1353 1476
Depth 1036 1036 1036 1086 1140
Flow/Return Connections (mm) Flow: DN65 Flange. Return RC2
Gas Inlet (BSP) RC1
1
/2
Flue Size (mm) 250 250 250 250 300
Maximum Working Pressure (bar) 6
Water Content (L) 53 53 60 68 76
Approx Dry Weight (kg) 520 520 587 654 721
Front (mm) 700
Back (mm) 200
Side (mm) 100 (not including clearance for side fitted flow header)
General Data Concord CXSi/H (110 - 180)
Boiler
Clearances
Concord CXSi/H 110 - 180kW
12
gas atmospheric
