Horizontal assembly
High efficiency 85% (gross)
Low NOx emissions (class 5)
100kW Modules
Ultra compact
Sequence controlled
Easy to install and service
Model 200/S 300/3 300/3A 400/4 400/4A 500/5 600/6
Modules 2334456
Output (kW) 200 300 300 400 400 500 600
Height 1800 1900 1900 1900 1900 1900 1900
Width 910 1510 2115 1510 2115 2115 2115
Depth 990 990 990 990 990 990 990
Flow/Return Connections (DN flange) 65 125 125 125 125 125 125
Gas Inlet (BSP) RC1
1
/
2
RC2 RC2 RC2 RC2 RC2 RC2
Flue Size (mm) 250 350 350 450 450 450 450
Maximum Working Pressure (bar) 6
Water Content (L) 19.8 29.7 29.7 39.7 39.7 49.5 59.4
Approx Dry Weight (kg) 328.3 466.4 466.4 546.1 546.1 715.6 794.6
Front (mm) 900
Back (mm) 25
Left (mm) 500
Right (mm) 500
General Data Super Plus (200 - 600)
Option Kits
Boiler
Water flow switch for boiler protection in
the event of pump failure
Remote indication of boiler on,
lockout and overheat for each module
Module blanking off pack
Super Plus
Boiler
Clearances
Super Plus 200 - 600kW
15
