4
condensing
icos HE 30 + 36kW
• Wall mounted
• Robust cast aluminium heat exchanger
• Compact
• Easy to install and service
• Modulating output down to 10.4kW
• Wide range of flue options
• Optional remotely mountable user controls
Model 30 36
Boiler Output (condensing) 50/30˚C 11.4 - 32.8 11.4 - 39.8
Boiler Output (non-condensing) 80/60˚C 10.4 - 30.1 10.4 - 37.0
Height 645
Width 450
Depth 410
Flow/Return Connections (mm) 28
Gas Inlet (BSP) RC
1
/
2
”
Flue Size (mm)
Concentric 60/100 60/100
Twin Pipe 80/80 80/80
Maximum Working Pressure (bar) 3
Water Content (L)
4.7 4.7
Approx Dry Weight (kg) 52.6 52.6
Top (mm) 165
Below (mm) 150
Left (mm) 15
Right (mm) 15
Front (mm) 450
Condensate Drain (mm) 21.5
General Data icos HE (30 + 36)
Boiler
Clearances
Option Kits
Boiler icos HE 30 + 36
Remote user control kit ✓
Stand off kit ✓
Syphon kit ✓
Condensate pump kit ✓
