IDEAL Evomax 120 Installation & Servicing Manual

61
EVOMAX -
Installation & Servicing
SHORT LIST OF PARTS
The following are parts commonly required as replacements,
due to damage or expendability.
A full list of spares is held by Ideal Stelrad Group distributors
and merchants.
Their failure or absence will affect the safety and/or
performance of this appliance.
When ordering spare parts please quote:
1. Boiler model
2. Boiler serial no. (refer to the data plate on boiler)
3. Boiler P.I. No. (refer to the data plate on boiler)
4. Description
5. Quantity
6. Part no.
Key No. Description Qty. Part No.
When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance
specication that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal.
105 Auto Air Vent 1 172668
207 Burner Seal kit 30/40kW 1 176363
207 Burner Seal kit 60/80kW 1 176364
207 Burner Seal kit 100/120kW 1 176365
207 Burner Seal kit 150kW 1 176366
208 Burner Fixings Kit 1 176367
230 Fan 30/40/60kW 1 176272
230 Fan 80/00kW 1 176273
230 Fan 120/150kW 1 176274
231 Gas Valve Kit 30/40/60/80/150kW 1 176313
231 Gas Valve Kit 100/120kW 1 176358
232 Venturi Kit 30kW 1 176359
232 Venturi Kit 40kW 1 176360
232 Venturi Kit 60kW 1 176361
232 Venturi Kit 80/150kW 1 176362
232 Venturi 100kW 1 175232
232 Venturi 120kW 1 174381
233 Orice (Ø4.75) Kit 30kW 1 176368
233 Orice (Ø3.4) Kit 30PkW 1 176558
233 Orice (Ø5.25) Kit 40kW 1 176369
233 Orice (Ø3.9) Kit 40PkW 1 176559
233 Orice (Ø7.8) Kit 60kW 1 176370
233 Orice (Ø5.7) Kit 60PkW 1 176560
233 Orice (Ø8.0) Kit 80/150kW 1 176371
233 Orice (Ø5.9) Kit 80PkW 1 176561
233 Orice (Ø8.8) Kit 100/120kW 1 176373
301 Dry Fire Thermistor Kit 1 176203
302 Lead Ignition Kit 1 176204
303 Lead - HT Earth Kit 1 176205
304 Ignitor Unit 1 175593
305 Electrode Detection Kit 1 176206
306 Ignition Electrode Kit 1 176207
308 Fascia Plastic 1 176209
309 HMI Board 1 176210
310 Primary PCB 1 176211
501 Jacket Assembly Evomax Kit 1 176374
502 Door Assembly Evomax Kit 1 176375
