Fig. 46 - EXALT Control & Display Enclosures

CHAPTER 18

CHAPTER 18 - REPLACEMENT PARTS

Item Part # Description

1 EXRKIT52 Control Module

2 EXRKIT86 Control Box Hinges

3 EXRKIT53 Display Module

4 EXRKIT55 Control Enclosure
