IDEAL F80 - Page 29

29
xtra
- Installation & Servicing
INSTALLATION
DHW type 13
x0=N/A
x1=N/A
x2=Storage tank with tank sensor kit
x3=Storage tank with DHW cylinder thermostat
x4=N/A
x5=N/A
x6=N/A
x7=N/A
x8=N/A
x9=External heat request (by control interface kit)
0x=3 way valve normally open
1x=hot water pump
2x=3way valve normally closed
Press Display
Factory
Setting
Upper
Limit
Lower
Limit
Description
. 0 0
CH type 00
x0=Room thermostat
x1=Outside temperature
x2=N/A
x3=N/A
x4=0-10V: capacity (using BMS 0-10V kit)
x5=0-10V: temperature (using BMS 0-10V kit)
x6=+/- control
x7=NTC6 on AM4 + RT: capacity
x8=0-10V on AM4 + RT: temperature
0x=N/A - First digit factory set to '0'. Do not adjust
1x=N/A - First digit factory set to '0'. Do not adjust
2x=N/A - First digit factory set to '0'. Do not adjust
3x=N/A - First digit factory set to '0'. Do not adjust
4x=N/A - First digit factory set to '0'. Do not adjust
5x=N/A - First digit factory set to '0'. Do not adjust
6x=N/A - First digit factory set to '0'. Do not adjust
7x=N/A - First digit factory set to '0'. Do not adjust
8x=N/A - First digit factory set to '0'. Do not adjust
45
P45
. 1 3
46
P46
. - 0 1
47
P47
Manual fanspeed (for service use) -01 100 -01
Note -1=off
00 = min fan speed
50 = mid rate
100 = max fan speed
48
49
50
51
N/A
53
Low/Off cycle
00
x0=off
x1=on
Special pump function CH/DHW
0x=CH normal pump function, DHW normal pump function
1x=CH pump off during heat request, DHW normal pump function
2x=CH pump normal function, DHW pump 5 sec on delay after
heat request
3x=CH pump off during heat request, DHW pump 5 sec on delay
after heat request
N/A Do not Do not 70
adjust adjust
54
Slow start
0=CH only 0 1 1
1=CH & DHW
56
32 ADVANCED CONTROLS ACCESS CONT'D
33 INFORMATION MODE (with code)
See Frame 25.
