45
xtra
- Installation & Servicing
SHORT LIST OF PARTS
The following are parts commonly required as replacements,
due to damage or expendability.
A full list of spares is held by Ideal Stelrad Group distributors
and merchants.
Their failure or absence will affect the safety and/or
performance of this appliance.
When ordering spare parts please quote:
1. Boiler model
2. Boiler serial no. (refer to the data plate on boiler*)
3. Boiler P.I. No. (refer to the data plate on boiler*)
4. Description
5. Quantity
6. Part no.
* Note. Data plate, (refer to Frame 6), can be accessed by
removing front panel, (refer to Frame 45).
Key No. Description Qty. Part No.
Per boiler
3 Pressure Gauge 1 172 669
8 Fan F80-F120 1 174 375
F160-F280 1 174 376
9 Gas Valve F80-F120 1 174 377
F160 1 174 378
F200-F280 1 174 379
12 Control Module F80 1 174 385
F120 1 174 386
F160 1 174 387
F200 1 174 388
F240 1 174 389
F280 1 174 390
13 Display Board 1 172 660
14 Alarm / Boiler Run Relays Board 1 174 391
21 Water Pressure Switch 1 172 667
26 Burner F80 1 174 405
F120 1 174 406
F160 1 174 407
F200 1 174 408
F240 1 174 409
F280 1 174 410
28 Gasket - Burner Manifold 1 174 412
29 Gasket - Fan F80-F280 1 174 413
30 Gasket - Fan F80-F120 1 174 414
31 Thermistor (temperature sensor) 4 174 415
33 Air Pressure Switch 1 174 418
36 Transformer 1 172 657
37 Relay 2 172 658
47 Ignition / Detection Electrode 1 174 432
51 Control Module Fuses 1 172 663
52 Mains Fuse 1 174 449
When replacing any part on this appliance use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal boilers.
