DD48 Series Display Units
Connector for Mother Board
Three types of connectors (with cable) are available for the mother board. The connector on the mother board has a strain relief to protect
the insulation displacement connection from external force.
4 kink pins each
on both sides
Cable Marking
Side
Marking
Marking
Decimal
Decimal
Binary
Binary
44.56
35.56
2.54
2.54
0.5
0.3
2.54
7.0
0.5
3.5
ø0.8min
2.54
±
0.08
35.56
±
0.08
Mother Board
Input Side
Connector
Mother Board
Cable Marking
Gray Cable
Data Input
Connector
Marking
For Direct Connection to PC Board
DD48-JE1A
[Input Side Connector]
Flat cable connector for direct connection to PC board
Dimensions PC Board Drilling Layout
Terminal Arrangement (Bottom View)
Marking
Marking
Decimal
Decimal
Binary
Binary
5.67.0
15.9
2.54
1.27 3.81
2.54
6.0
0.38
42.67
±
0.2
35.56
±
0.2
Mother Board
Input Side
Connector
Mother Board
Cable Marking
Gray Cable
Data Input
Connector
Marking
For Connection to Connector Header
DD48-JE1B
[Input Side Connector]
MIL at cable connector (with strain relief)
IDEC’s JE1S-301 (with strain relief)
Dimensions
<Applicable Connector Header>
IDEC’s JE1H-301 (Right Angle)
IDEC’s JE1H-302 (Straight)
Terminal Arrangement (Bottom View)
(Color-coded Cable)
Cable Marking
Decimal
(Name)
(Terminal No.)
(Cable Color)
Black White Gray Purple Blue Green Yellow Orange Red Brown Black White Gray Purple Blue Green Yellow Orange Red Brown Black White Gray Purple Blue Green Yellow Orange Red Brown
Binary
36.83
1.27
38.10
0.89
Mother Board
Mother Board
Cable Marking
Color-coded
Cable
Data Input
Connector
For Soldering Connection to PC Board or Others
DD48-JE1C
[Input Side Connector]
Not provided (soldering, etc.)
Flat Cable
Material
Conductor
AWG28 (7 cores/0.127mm)
Tinned annealed copper wire
Insulator Heat-resisting vinyl
Note: Specify a cable length code (0.5: 500 mm, 1: 1000 mm, 2: 2000 mm, 3: 3000 mm, 4: 4000 mm, 5: 5000 mm) in place of
in the Part No.
