IDEC DD3S Series - Accessories; Specifications

5
DD3S Series Display Units
Accessories (Optional)
Name Part No.
Spacer Unit Black DD9Z-FY1-B
End Plate (pair) Black DD9Z-W-B
Connector
Solder Terminal DMC-1
PC Board Terminal DMC-2
Retentive/One-way
Insertion Connector
Solder Terminal DD9Z-CN1
Connector Stopper DD9Z-ST1
Mother Board
for binary/decimal/hex/
extra decimal display
unit
Dynamic
4-digit DD9Z-MB1-4
2-digit DD9Z-MB1-2
Static
4-digit DD9Z-MB2-4
3-digit DD9Z-MB2-3
2-digit DD9Z-MB2-2
Mother Board
for 5 × 7 dot matrix
character display unit
(with spacer)
4-digit DD9Z-MB3-4
Mother Board
Connector
Type A
DD9Z-JE1A
Type B
DD9Z-JE1B
Type C
DD9Z-JE1C
Coupling Spacer
for IDEC DG Series
Digital Switches
Right Side Black DD9Z-FG1R-B
Left Side Black DD9Z-FG1L-B
Cable Length Code
Specify a cable length code in place of  in the Part No. of mother
board cable types A, B, and C. These cables can be used for both
dynamic and static type mother boards.
Code 01 02 03 05 10
Cable Length (mm) 100 200 300 500 1000
Code 15 20 30 40 50
Cable Length (mm) 1500 2000 3000 4000 5000
Specifications
Power Voltage 12 to 24V DC ±10%
Current Draw
Binary
35 mA max. (red)
50 mA max. (green)
Decimal/
Hex/
Extra decimal
40 mA max. (red)
60 mA max. (green)
2-color: 60 mA max. (green)
Character
Display
65 mA max.
Data Input Level
L: 0 to 2V
H: 9 to 30V
Display
Character
(see Function
Tables)
•Binary display unit
Red or green LED: +, –, 1, decimal point
•Decimal display unit
7-segment 1-color (red or green), 2-color
(red/green) LED: 0 to 9, decimal point
•Hexadecimal display unit
7-segment 1-color (red or green), 2-color
(red/green) LED: 0 to 9, A to F, decimal point
•Extra decimal display unit
7-segment 1-color (red or green), 2-color
(red/green) LED: 0 to 9,
–
, –,
–
,
=
, =, decimal
point
Character Height
•Binary display unit: 15 mm
•Decimal/Hex/Extra Decimal display units:
15.2 mm (2-color: 15 mm)
•Character display unit: 17.8H × 12.7W mm
Input
•Binary display unit
+, –, 1, Latch, BL, LT, DP
•Decimal/Hex/Extra Decimal display units:
<Standard>
Binary, Latch, BL, LT, DP
<Zero-suppress>
Binary, Latch, BL, LT, DP, RBI
<2-color>
Binary, Latch, BL, R/G, DP
•Character display unit: D0 to D7, Latch, BL
Output
•Decimal/Hex/Extra Decimal display units:
<Zero-suppress>
RBO output
Input Logic Positive or negative
No. of Digits 8 digits max.
Unit
Combination
Snap t
Panel Mounting Snap t
Dielectric
Strength
•Binary/Decimal/Hex/Extra decimal display
units
Between live and dead parts :
1500V DC, 1 minute
•Character display unit
Between live and dead parts :
1000V AC, 1 minute
Insulation
Resistance
Between live and dead parts :
100 MΩ min. (500V DC megger)
Vibration
Resistance
(damage limits)
10 to 55 Hz, amplitude 0.25 mm
Shock
Resistance
(damage limits)
490 m/s²
Noise
Resistance
(operating
extremes)
•Binary/Decimal/Hex/Extra decimal display
unit
Power terminal (normal/common modes):
±1000V
Input terminal (normal/common modes):
±1000V
Output terminal (normal/common modes):
±500V
(Impulse condition: Pulse width 100 ns,
1 μs)
•Character display unit
Fast transient burst noise
Power supply: 2 kV, Signal: 1 kV
(IEC61000-4-4 capacitive clamp)
Operating
Temperature
–10 to +55°C (no freezing)
Storage
Temperature
–25 to +80°C (no freezing)
Operating
Humidity
35 to 85% RH (no condensation)
Power Inrush
Current
•Binary/Decimal/Hex/Extra decimal display
unit
Approx. 2.0A (Power voltage: 24V)
•Character display unit
Approx. 1.0A (Power voltage: 24V)
Degree of
Protection
IP40 (IEC60529)
Weight (Approx.)
•Display unit: 16g
•End plates: 4.5g (pair)
