IDEC DD3S Series - Page 3

3
Series
DD3S DD48 DD96
Shape
Unit Type Binary Decimal/Hexadecimal/Extra Decimal Character Display
Binary Decimal Decimal
Display Part (mm)
+, –, 1
Red or green LED
7-segment
Red LED, Green LED
Red/green 2-color alternate LED
Notes:
The red and green colors of the
single color LEDs are different
from those of the 2-color
alternate display.
Red LED
– (minus)
Red or green LED
7-segment
Red or green LED 7-segment
Red LED
Display Character
+, –, 1
decimal point
Decimal display unit: 0 to 9, decimal point
Hexadecimal display unit: 0 to F, decimal point
Extra decimal display unit: 0 to 9,
–
, –,
–
,
=
, =, decimal point
254 characters
– (minus)
0 to 9
Decimal point
0 to 9
Decimal point
Function Standard Standard 2-color alternate Zero-suppress — — — —
Input
+, –, 1
Latch
BL
LT
DP
Binary
Latch
BL
LT
DP
Binary
Latch
R/G
BL
DP
Binary
Latch
BL
LT
RBI
DP
Data (8-bit) input
Latch
BL
–
Latch
BL
Binary
Latch
DP
RBI
Binary
Latch
DP
BI
Output — — — RBO — — RBO BO
Input Logic Positive or negative Positive or negative Negative
Data Input Level
L: 0 to 2V
H: 9 to 30V
L: 0 to 2V
H: 12 to 30V
L: 0 to 2V
H: 12 to 30V
Power Voltage 12 to 24V DC ±10% 24V DC ±10% 24V DC ±10%
Current Draw
(Power Consumption)
(approx.)
Red: 35 mA max.
Green: 50 mA max.
Red: 40 mA max.
Green: 60 mA max.
60 mA max.
Red: 40 mA max.
Green: 60 mA max.
65 mA max.
0.9W 2.0W 80 mA
No. of Digits 8 digits max. (1 digit/unit) 16 digits max. (1 digit/unit) 8 digits max. (1 digit/unit)
Panel Mounting Front mount, snap t Front mount, snap t
Front mount: Snap t
Rear mounting: Screw mounting
Housing Color Black (End plate: black) Black or beige Black
Connector
•Solder terminal, PC board terminal, wire-wrap terminal (optional)
•Mother board: Dynamic (4- or 2-digit, optional)
Static (4-, 3-, or 2-digit, optional)
•Mother board: 4 digits (optional)
(For character display)
•Solder terminal, PC board terminal (optional)
•Mother board: 4-digit (optional) for mounting binary and decimal units
•Solder terminal (supplied)
Dimensions
33H × 20W × 45.5D mm/unit 48H × 30W × 79D mm/unit
Front mount: 96H × 72W × 42.5D mm/unit
Rear mount: 90H × 72W × 41D mm/unit
Weight (approx.)
Display unit: 16.0g
End plates (pair): 4.5g
Display unit: 50g
End plates: 20g (pair)
Front mount: 130g
Rear mount: 100g
End plates: 26g (pair)
See Page 4 through 18 19 through 26 27 through 30
Front Mount
Rear Mount
6.2
6.2
33
13.2
20
33
20
883
14.2
33
20
17.8
12.7
48
30
2.5
11.1
25.4
14
48
30
57
96
33
72
Display Units (Selection Guide)
