Idis DR-2204P - Audio Detection

Part 2 - Conguration
56
Face Detection
When face detection event occurs in the selected
camera, the area that the face is detected displays on
the screen.
● No.: Select which cameras to apply Face Detection to.
● Sensitivity: Set sensitivity settings between 1 (Low)
and 5 (High).
● Max. Detect Count: Set the maximum detected
number of face as 8 or 32.
When you set the Max. Detect Count as 32, the
sensitivity feature will be disabled.
● Min. Face Size: Select 120 x 120, 150 x 150, 180 x180,
210 x 210 or 240 x 240.
● Actions: Specify which actions to take when a Face
Detection event occurs.
– Record: Specify which cameras to begin linked
recording on when an event occurs. If the schedule
is set to Event or Time & Event mode, the selected
cameras will begin linked recording when an event
occurs.
– Alarm-Out: Designate event-triggered alarm-out
channels (each for the NVR and camera) and beeps.
– Notify: Congure to be notied of events by Mail,
LAN1 through 5, SNS, Push, and/or Alert Window.
– EventUpload: Uploads the video clips when an
event occurs.
– PTZ: Moves the PTZ camera to a specic preset
position when an event occurs.
– Event Monitoring: Selects the cameras to monitor
when an event occurs.
• In order to use the Callback feature, the NVR
must be registered on the remote program.
• In case of the camera that not supports face
detection event, the face detection feature will
be disabled.
● Ignoring Interval: The system does not produce
event log entries or issue remote notications
regarding face detected for the time specied
after the initial motion was detected. Set the value
between 1 sec and 5 secs or choose Never.
