Location 22 – 40: Programmable Output Options
Outputs are used to trigger many different devices, the most common being a radio transmitter which
transmits signals back to the alarm monitoring company.
The IDS 805 has 5 positively triggered outputs. Each output triggers with, direct current (DC) 12V and
can supply approximately 100mA of current. If more current is required please use a 12V positively
triggered relay to supply current from a different power source.
Outputs can be set to pulse or latch.
Pulse: The output will rise from 0V to 12V remain at 12V for 3 seconds and return to 0V.
Latch: The output will rise from 0V to 12V and remain in this state until another trigger forces it to go
back to 0V. A light switch is an example of latching as once switched on the light will only go off
again when the switch is returned back to the off position.
Locations and their default values
Panel does a test to the monitoring company
A duress code can be entered
The alarm has triggered and a valid user code has
been entered
Triggered when the [F] key is pressed or a fire zone
triggers
This output will latch when an alarm is registered
and will only unlatch once a valid user code is
entered
If tamper per zone or a zone is made a tamper
zone and the tamper condition is triggered will this
output be triggered
The siren will not sound but this output will trigger
once programmed to alert the monitoring
company.
If a chime zone is triggered in the unarmed state,
this output will trigger
If the alarm cannot communicate via the phone
line, this output can trigger another device to alert
the monitoring company of a problem
To Next Page
