IDS 805 Training Manual

Location 47: Primary Communicator Format
For 805:
This is the communication language that the alarm system must use to communicate with the device at
the alarm monitoring company.
Tx = Transmit HS = Handshake PPS = Pulse per Second
Note: Contact ID and Sescoa Superfast are the only formats that when chosen will enter all the reporting
codes, into the locations.
For 805s:
The serial communication is Contact ID only and must be enabled when needed.
Location 48 to 63: Primary Telephone Number (805 Only)
Rules when entering telephone numbers:
1. If the number contains any zeros, all zeros [0] must be entered as tens [1][0].
2. To dial a [*] enter a eleven [1][1]
3. To dial a [#] enter a twelve [1][2]
4. A 12 second pause, enter a fourteen [1][4]
5. A 4 second pause, enter a fifteen [1][5]
6. To end the number in the next location after the last digit of the number being dialled, enter a zero,
[0].
Example of entering a phone number:
Number to be dialled: 0 to get a line, 4 second pause, 08607051373.
Location
48
49
50
51
52
53
54
55
56
57
58
59
60
61
Digits
10
15
10
8
6
10
7
10
5
1
3
7
7
0
NB: Location 61 has a zero to terminate the telephone number.
Location 64 to 79: Secondary Telephone Number/Serial Telephone Number
805: This is the second number that can be dialled as a backup for the primary number should there be
a failure to communicate on that number. The same rules apply as the primary telephone number.
805s: This is the number that the serial device will dial to make the connection to a receiving unit, if the
serial device is made to use a telephone number.
Value
Action
Description
0
Sescoa Superfast
1.8kHz Tx, 2.3kHz HS
1
Ademco Express
Dual Tone HS, DTMF
2
FBI 4 x 2 (No Parity)
1.8kHz Tx, 2.3kHz HS, 20PPS
3
FBI 4 x 2 (Parity)
1.8kHz Tx, 2.3kHz HS, 40PPS
4
Sescoa / Franklin Fast
1.8kHz Tx, 2.3kHz HS, 20PPS
6
Contact ID
Dual Tone HS, DTMF
7
Domestic Reporting
1.8kHz Tx, Blind, 20PPS
12
Silent Knight 4 x 2 Fast
1.9kHz Tx, 1.4kHz HS, 20PPS
Value
Action
0
Off
6
On

IDS 805 Specifications

General

Zones	8
Model	IDS 805
Backlight	Yes
Voltage	12V DC
Current	50mA
Display	LED
Operating Temperature	-10°C to +50°C
