IDS X16 User Manual

26
Communication Settings | IDS X Series Training V2.3
Location 51 to 54: Entering a telephone number
Location Type: Standard
When entering phone numbers please follow the following instructions:
To dial a “*” enter [MODE] [1]
To dial a “#” enter [MODE] [2]
For a “12-second pause” enter [MODE] [3] (On the LCD keypad it will be displayed as a “+”)
For a “8-second pause” enter [MODE] [4] (On the LCD keypad it will be displayed as a “=”)
For a “4-second pause” enter [MODE] [5] (On the LCD keypad it will be displayed as a “-“)
Note: [MODE] [0] will clear the phone number
Exercise:
The control room‟s phone number is 0860105937. The alarm is installed in a building with a
switchboard and 0 has to be dialled to get a line and then must wait 4 seconds before dialling.
Instructions
Key presses
Enter location 51
[5][1] [*]
Enter the value needed to dial
[0] [mode] [5] [0] [8] [6] [0] [1] [0] [5] [9] [3] [7] [*]
Location 55: Serial Reporting Telephone Number
Location Type: Standard
The telephone number the serially connected device must dial to report any signals.
Note: This option is only entered if the serial device has this option built in.
Location 61 to 68: Primary Account Codes per Partition
Location Type: Standard
The account code is what identifies the alarm system to the security company so that they can respond to
the correct customer. It is by default a four digit number but can be changed in location 24 to a six digit
number.
Exercise:
Enter an account code 0123
Instructions
Key presses
Enter location 61
[6][1] [*]
Enter the account Code
[0] [1] [2] [3] [*]
Note: If the account code is 0000 no reporting will take place. This also allows you to configure
which partitions report and which do not.
Location 71 to 78: Secondary Account Codes
Location Type: Standard
The secondary account code is used if double dual report dial is enabled and the second telephone
dialleddial must have a different account code to the primary account code.
Note: If the account code is 0000 no reporting will take place. This also allows you to configure
which partitions report and which do not.
