IDS X16 User Manual

Location
Sub
Loc.
Description
Explanation
304 to 307
1 to 16
Zone alarm reporting
When the system is armed, a 24Hr zone or a panic zone is triggered
this code is reported
308 to 311
1 to 16
Zone alarm restoral
When the zone restores after being violated this code is sent
312 to 315
1 to 16
Zone tamper reporting
If the tamper monitoring option is enabled and a tamper signal is
received this code is sent
316 to 319
1 to 16
Zone tamper restoral
Once the tamper condition is corrected a restoral is sent
320 to 323
1 to 16
Zone bypass reporting
If a zone is bypassed and the alarm is armed this code is sent to
report which zones are inactive
324 to 327
1 to 16
Forced Arming
If the system is programmed to automatically bypass zones that are
violated when arming, this code is sent to alert the monitoring
company of inactive zones
328 to 331
1 to 16
Swinger shutdown
reporting
If swinger shutdown has been enabled and the alarm automatically
shuts down a zone that has violated the swinger shutdown settings
332 to 335
1 to 16
Swing shutdown restore
The system can be set to try and restore a zone that has been
disabled by the swing shutdown option and if it is able to restore the
zone this code is sent
Extending Contact ID Zone Reporting
Location Type: Extended
Locations 304 to 335 can be programmed with a value that will change the contact ID reporting code for
each zone to extend what can be connected to each zone and what is reported to the control room.
Example: If a gas detector is connect to zone 8
By entering 26 into location 304 sub-location 8, whenever zone 8 triggers a contact ID code, 151 (Gas
detected), is sent to the control room.
Please see Appendix at the end of the manual for all values.
Value
CID
Description
Value
CID
Description
01
100
Medical Zone
3C
303
RAM Checksum bad Zone
02
101
Personal Emergency Zone
3D
304
ROM checksum bad Zone
26
151
Gas detected Zone
3E
305
System reset Zone
28
153
Loss of heat Zone
3F
306
Panel programming changed Zone
Location 336 to 340: Partition reporting codes
Location Type: Extended
There is a sub-location for each of the 8 partitions.
[INSTALLER CODE] [*] [LOCATION] [*] [SUB LOC] [*] [REPORTING CODE] [*]
Loc
Sub Loc
Description
Explanation
336
1 to 8
Duress reporting
A user code can be programmed to send a duress signal to alert the security
company of a life threatening situation causing the user to disarm the alarm with
this code
337
1 to 8
Keypad panic
Each keypad has a panic button which when pressed can send a code alerting the
monitoring company of a situation
338
1 to 8
Fire alarm
If a fire is detected or the fire key is pressed this code will be reported
339
1 to 8
Medical Key
A medical code is sent alerting the monitoring company to send an ambulance
340
1 to 8
Keypad lockout
If a code is entered incorrectly the keypad can be set to lock for a period of time
and sent this code to alert the monitoring company
