Reporting Codes | IDS X Series Training V2.3
Location 302 Global reporting
Location Type: Extended
Sub Loc.
Description
Explanation
1
Bus device tamper
When a device that is connected to the keypad bus registers a tamper this
code is sent to the alarm company
2
Bus device tamper
restore
When the device on the bus registers that the tamper condition has been
restored it will send this code
3
Bus peripheral
Communication fail
When a device that has been registered on the bus stops communicating the
control panel will send this code to alert the company monitoring the alarm
4
Bus peripheral
Communication
restore
Once the communication between the control panel and the missing device is
corrected a restoral is sent to the alarm company
5
Bus peripheral
power/battery low
A device that has the ability to monitor its power detects that it‟s power is low a
message can be sent
6
Bus peripheral
power/battery restore
Once the power is restored a signal alerting the monitoring company can be
sent
7
Wireless detector
battery low
Wireless devices monitor their batteries and when a battery needs changing
this low battery code is sent
8
Wireless detector
battery restore
After changing the battery a restoral is sent
Location 303 Global reporting
Location Type: Extended
Sub Loc.
Description
Explanation
1
Wireless detector
supervision failure
Each device checks in with the controller at a predetermined time and if this signal
is not received, the alarm company is alerted that it has gone missing
2
Wireless detector
supervision restore
When the wireless device starts communicating after being missing a restoral is
sent
3
Wireless receiver
signal jam
If the receiver detects a signal that could block effective communication from the
devices that it is monitoring an alert is sent to the monitoring company
4
Wireless receiver
signal restore
When the signal causing the jam has been removed a restoral is sent
5
Wireless Detector
RSSI low
Each detectors signal strength is checked and if the signal strength drops below
20% a low RSSI is sent
6
Wireless Detector
RSSI restore
Once the signal strength of a device increases above 20% a RSSI restore is sent
7
Dedicated Panic
On board is a dedicated panic zone, when triggered this code is sent
8
Test report
The X-Series can be programmed to send test signals to confirm that it is still alive
9
Download report
code
After the system has been connected to by IDSwift software a code is sent.
Location 304 to 335: Zone reporting
Location Type: Extended
Each location represents a set of 16 zones:
 Location 304 is zones 1-16
 Location 305 is zones 17-32
 Location 306 is zones 33-48
 Location 307 is zones 39-64
monitor the box that it is in so it cannot be opened without notifying the
security company
8
Box tamper restore
When the box is closed a restore is sent
