IDS X16 User Manual

IDS X Series Training V2.3 | Default 5
61
Location 571 Global Split Reporting 1
LED
Factory
Default
Default
5
Action
LED
On/Off
Reporting Pair
1
ON
ON
AC fail reporting
9
OFF
Telephone module 1
2
OFF
OFF
Communication fail reporting *
10
OFF
Telephone module 1
3
ON
ON
Telephone line tamper reporting
11
OFF
Telephone module 1
4
ON
ON
Siren fail reporting
12
OFF
Telephone module 1
5
ON
ON
Panel low battery fail reporting
13
OFF
Telephone module 1
6
ON
ON
Aux 12V fuse fail reporting
14
OFF
Telephone module 1
7
Reserved
15
Reserved
8
ON
ON
Box tamper reporting
16
OFF
Telephone module 1
Location 572 Global Split Reporting 2
LED
Factory
Default
Default
5
Action
LED
On/Off
Reporting Pair
1
ON
ON
Bus-wired peripheral tamper
reporting
9
OFF
Telephone module 1
2
ON
ON
Bus-wired peripheral fail reporting
10
OFF
Telephone module 1
3
OFF
OFF
Bus-wired peripheral low battery
reporting *
11
OFF
Telephone module 1
4
ON
OFF
Wireless Detector Battery Low
12
OFF
Telephone module 1
5
OFF
OFF
Wireless Detector Supervision fail
13
OFF
Telephone module 1
6
OFF
OFF
Wireless Receiver Signal Jammed
14
OFF
Telephone module 1
7
OFF
OFF
Wireless Detector RSSI Low
15
OFF
Telephone module 1
8
ON
ON
AC Restored
16
OFF
Telephone module 1
Location 573 Global Split Reporting 3
LED
Factory
Default
Default
5
Action
LED
On/Off
Reporting Pair
1
OFF
OFF
Comms Restored
9
OFF
Telephone module 1
2
OFF
OFF
Comms Tamper Restore
10
OFF
Telephone module 1
3
OFF
OFF
Siren Restore
11
OFF
Telephone module 1
4
ON
ON
Battery Restore
12
OFF
Telephone module 1
5
OFF
OFF
Aux 12V Restored
13
OFF
Telephone module 1
6
OFF
OFF
Installer Reset restored
14
OFF
Telephone module 1
7
OFF
OFF
Box tamper restored
15
OFF
Telephone module 1
8
OFF
OFF
Bus device tamper restored
16
OFF
Telephone module 1
